AA36-ECF Tie Line Manual SM42 Rev. 4.00
2.4 Continued
Airworthiness
Maintenance of the AA36-ECF is ‘on condition’ only. Periodic maintenance of this
product is not required.
2.5 Accessories Required But Not Supplied
Installation kit p/n AA36-IKC (crimp) is required to complete the installation. Each kit
consists of the following:
AA36-IKC 25-pin D-min Female Crimp Kit (NAT Part No. D25SL-IKC)
Quantity Description NAT Part #
1
D-min 25 Socket Housing 20-21-025
25 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 Pin Connector Hood 20-29-026
* Use as required.
2.6 Installation Drawings
DRAWING REV. DESCRIPTION TYPE
AA36\ECF\403-0 1.00 ICS TIE Line Adapter Interconnect
AA36\ECF\405-0 1.00 ICS TIE Line Adapter Connector Map
AA36\ECF\922-0 1.00 ICS TIE Line Adapter Mechanical installation
Section 2.0 ends after these Drawings
