Section 1.0 Description
1.1 Introduction
This manual contains information on the LL08 Legend Lamp.
Information in this section consists of purpose of equipment, features and specifications.
1.2 Purpose of Equipment
The LL08 is a two-section legend lamp with changeable legends. It is designed for use
with the RS series of remote switches from NAT.
1.3 Features
Styled to look the same as its companion illuminated switch, the PB08, the LL08 allows
a clean, integrated panel appearance. Two independent lamps are included in the
LL08, each with isolated terminals.
It is shipped assembled (but with no legends inserted) and with 28 V lamps installed.
The desired legends must be cut from the sheet provided and inserted inside the lens
cap. If 14 V operation is required, substitute type 386 lamps.
1.4 Specifications
1.4.1 Electrical Specifications
Input Power +14/+28 Vdc at 200 mA max.
Lamps Type 388 for 28 Vdc operation
Type 386 for 14 Vdc operation
1.4.2 Physical Specifications
Height 0.71 inches (17.9 mm)
Length 1.33 inches (33.8 mm)
Width 0.94 inches (23.8 mm)
Mounting Front mounting, held in place by compression fingers
Mounting hole height 0.59 inches (14.9 mm)
Mounting hole width 0.82 inches (20.8 mm)
