2.3.4 Changing Lamps
To replace or change lamps, withdraw the lens/diffuser assembly and pull out the lamp
with a pair of needle-nosed pliers. Push in a new lamp and press down on the top of
the lamp with the end of a pencil eraser or other object until the lamp clicks into place.
When it is correctly seated, it will not move farther in. Replace the lens assembly.
2.4 Continued Airworthiness
Maintenance of this product is on condition only. Periodic maintenance of this product
is not required.
2.5 Drawings
DRAWING REV. DESCRIPTION TYPE
LL08\904-0
1.10 LL08 Legend Lamp Exploded View
LL08\922-0 1.02 LL08 Legend Lamp Mech. Installation
LL08\001\701-0 1.10 LL08 Legend Lamp Parts List
Section 2.0 ends after these Drawings
