■ Multi-Function Preset Memory Remote Controller with Glo-keys
The supplied system remote controller features a large selection of remote control
codes to operate other components in your home theater system, including codes for
selected DENON models, along with remote control codes from other manufacturers.
The most frequently used buttons are laid out separately for TV, VCR and DVD, for
maximum ease-of-use.
* Remote control codes may not be available for some products of other manufacturers
■ DENON's Latest Surround Technology Faithfully Recreates the
Surround Sound Produced at the Dubbing Stage.
• DTS 96/24 Decoding for DVD-Video
• DTS-ES Discrete 6.1 and Matrix 6.1
• DTS NEO:6
• Dolby Digital EX
• Dolby Pro Logic IIx
■ 7 Channel Stereo Mode
DENON's popular 7 Channel Stereo mode transforms your favorite 2-channel
sources such as CD, tape, stereo radio and stereo video sources into exciting surround
sound, free of delay effects and unnatural artifacts, from all six speakers. This 7
Channel Stereo mode was originally developed by DENON to enhance music lovers'
enjoyment with home theater ambience.
■ Adjustable Cross-Over Switching
The AVR-1905 supports subwoofer cross-over switching with a choice of
8 cross-over
frequencies: 40/60/80/100/120/150/200/250 Hz. This lets you more accurately match the
performance characteristics of the subwoofer to the main speaker system.
■ Support for Multi-Zone Configurations
The AVR-1905 provides a Multi Zone Output function and a Select function that let
you output different surces to multiple zones. Sources can be selected for output to
an additional zone, in addition to the main room.
■ Multi Zone Power Amplifier Assign
The AVR-1905’s Power Amplifier Assign function lets you assign the Surround Back
amplifier channel s when the system is not configured for 7.1 to instead drive the
Multi-room Zone 2 speaker s, with 80 Watts per channel output power, while
still providing 5 discrete amplifier channels to drive all speakers in the 5.1 configured
home theater room.
■ REC OUT Selector
■ All ch
annel Preamp outputs
■ Front Panel Inputs (with S-Video, Digital Optical Input)
■ Front A/B Speaker Terminals
■ High-grade
7 Channel Speaker Terminals (All ch)
■ Frequency Synthesis Tuning
• 56-Station AM/FM Random Preset Memory Tuning
• Auto Preset Memory
Specifications
■ Input/Output Terminals For Every A/V System
• Audio Inputs
8 Analog Inputs.................................... CD, (TUNER), DVD/VDP, TV/DBS, AUX,
VCR, CDR/TAPE, V.AUX(FRONT)
6 Analog EXT. Input ............................ FRONT L/R, CENTER,
SURROUND L/R, SUBWOOFER
3 Digital (Optical) Input ........................ OPTICAL X 3
1 Digital (Coaxial) Input ....................... COAXIAL X 1
• Audio Outputs
1 Analog PRE OUT Terminals............. 7.1 ch
2 Analog REC OUT Terminals.............. VCR, CDR/TAPE
1 Analog Multi Zone 2 Output.............. L/R
1 Digital (Optical) Output ..................... OPTICAL x 1
• Video Inputs
3 Component Video Input.................... VIDEO1, VIDEO2, VIDEO3
4 Composite Inputs.............................. DVD/VDP, TV/DBS, VCR-1,
V.AUX(FRONT)
3 S-Video Inputs ...................................... DVD/VDP, TV/DBS, VCR
• Video Outputs
1 Component Video Output ................. MONITOR
2 Composite Outputs........................... VCR, MONITOR
2 S-Video Outputs ............................... VCR, MONITOR
■ Power Amplifier Section
Rated output *THD figures are power amp stage values.
Front.......................................... 80 W + 80 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
Center ....................................... 80 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W (6 ohms, 1 kHz, 0.7 % THD)
Surround................................... 80 W + 80 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
Surround Back ........................ 80 W + 80 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
■ Preamplifier Section
Input sensitivity/Impedance
CD, DVD/VDP, TV/DBS, VCR, CDR/TAPE, AUX,
V.AUX(FRONT)................. 200 mV/47 kohms
Output level/Load impedance
SUBWOOFER................... 1.2 V/10 kohms
CDR/TAPE, VCR, ZONE2
.......................................... 200 mV/47 kohms
Frequency response .............. 10 Hz - 100 kHz (+1, -3 dB) (Tone Defeat On)
Signal-to-noise ratio............... 100 dB (IHF-A weighted) (Tone Defeat On)
Tone control........................... Treble: ±12 dB at 10 kHz
Bass: ±12 dB at 100 Hz
■ FM Section
Tuning frequency range......... 87.5 - 107.9 MHz
Usable sensitivity ................... 1.0 µV (11.2 dBf)
■ AM Section
Tuning frequency range......... 520 - 1710 kHz
Usable sensitivity ................... 18 µV
■ General
Power supply ......................... AC 120 V, 60 Hz
Power consumption ............... 4.5 A
Dimensions ............................ 434 (W) x 171 (H) x 416 (D) mm
17.1” (W) x 6.7” (H) x 16.4” (D)
Weight.................................... 11.9 kg, 26.2 lbs
DENON ELECTRONICS (USA), LLC.
19C Chapin Road, Suite 205 Pine Brook, N.J. 07058-9385 USA
TEL: 973-396-0810 www.usa.denon.com
DENON CANADA INC.
505 APPLE CREEK BLVD. UNIT 5 MARKHAM, ONTARIO L3R5B1, CANADA
TEL : 905-475-4085 www.denon.ca
DENON, LTD.
3-16-11, YUSHIMA, BUNKYO-KU, TOKYO 113-0034, JAPAN
N E W M O D E L I N F O R M A T I O N AVR-1905
*Design and specifications are subject to change without notice.
*”Dolby”, “Dolby Digital”, “Pro Logic II”, “Dolby Digital EX” and
the double-D device are registered trademarks of
Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
