Page 19
19
103618
OWNER’S MANUAL
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
098511-138
Upper Shell
1
2
102432-01
Screw/Lockwasher, 1/2"
8
3
098512-31
Combustion Chamber
1
4
M16660
Photocell Bracket
1
5
HA3019
Photocell Assembly
1
6
M27417
Drain Plug
1
7
M10908-2
Screw, #6-32 x 3/8"
2
8
**
Burner Head Assembly
1
8-1
100735-15
Nozzle
1
8-2
M10659-1
Nozzle Seal Washer
2
8-3
M10809-1
Nozzle Seal Spring
1
8-4
M8882
Nozzle Seal Sleeve
1
8-5
M50924-03
Burner Head Body
1
8-6
M50820-02
Barb Fitting
2
8-7
104184-01
Spark Plug
1
9
102431-01
Screw/Lockwasher, 1/2"
13
10
M50814-06
Air Line
1
11
M51345-01
Fuel Line
1
12
102042-01
Fan
1
13
**
Motor and Pump Assembly
1
13-1
102001-03
Motor with capacitor
(230V/50Hz)
1
13-2
079975-02
Pump Body
1
13-3
FHPF3-5C
Screw, #10-32 x 5/8"
2
13-4
M22009
Insert
1
13-5
M22456-1
Rotor
1
13-6
M50545
End Pump Cover
1
13-7
M12179
Intake Filter
1
13-8
M16545
End Filter Cover
1
13-9
M8940
Steel Ball (1/4" Dia.)
1
13-10
M10993-1
Pressure Relief Spring
1
13-11
M27694
Adjusting Screw
1
13-12
M22997
Plug
1
13-13
M12461-31
Screw, #10-32 x 1"
4
13-14
M12244-1
Output Filter
1
13-15
M12461-31
Screw, #10-32 x 1"
6
13-16
M11637
Lint Filter
1
13-17
M50820-02
Barb Fitting
1
13-18
M8643
Blade
4
13-19
103229-01
Capacitor
1
14
M51114-01
Fan Guard
1
PARTS LIST
100,000 Btu/Hr Model
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
**Not available as an assembly, order parts separately.
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
15
M50631
Rubber Bumper
2
16
097468-01
Edge Liner
1
17
101206-01
Motor Bracket
1
18
WLE-3
Lock Washer, #10
2
19
NPF-3B
Nut, #10-32
3
20
NTC-4C
Hex locknut
2
21
102482-02
Electronic Ignitor
1
22
M11084-29
Screw, #10-16 x 3/4"
2
23
099125-13
Terminal Board
1
24
099157-01
Rivet
1
25
M50104-03
Bushing
1
26
M50104-03
Bushing
1
27
M50104-01
Bushing
2
28
099213-01
Button Plug
1
29
102801-01
Power Line RFI Filter
1
30
098511-191
Lower Shell
1
31
M11271-8
Clip Nut
8
32
RF3-6B
Screw, #10-32 x 3/4"
1
33
M51150-01
Fuel filter
1
34
M10990-3
Rubber Bushing
1
35
M51151-01
Fuel Line
1
36
098513-91
Fuel Tank
1
37
097702-01
Fuel Tank Cap
1
38
M16841-57
Wire Assembly (red)
1
39
097630-02
Flame-Out Control
1
40
M50400
Strain Relief Bushing
1
41
098872-03
Power Cord
1
42
M51077-01AA
Side Cover
1
43
099177-01
Hex Nut
1
44
078918-01
Terminal Board Tab Cap
2
45
079010-34
Wire Assembly (black)
2
46
097462-01
ON/OFF Switch
1
47
079919-01
Switch Cover
1
PARTS AVAILABLE - NOT SHOWN
HA2210
Filler Neck Screen
1
097650-01
Tradename Decal
2
M9900-192
Combustion Chamber
Ground Wire
1
103666-03
Decal Package
1
