Owner’s manual, Parts list – Desa BY150CEB User Manual
Page 15
15
103618
OWNER’S MANUAL
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
M51104-01
Handle
1
2
098511-54
Upper Shell
1
3
102432-01
Screw/Lockwasher, 1/2"
6
4
098512-43
Combustion Chamber
1
5
M51108-01
Heat Shield
1
6
M11084-29
Screw, #10-16 x 3/4"
2
7
M16660
Photocell Bracket
1
8
M10908-2
Screw, #6-32 x 3/8"
2
9
HA3019
Photocell Assembly
1
10
098872-03
Power Cord
1
11
**
Burner Strap Assembly
1
11-1
097124-01
Bracket
1
11-2
104183-01
Spark Plug
1
11-3
079980-01
Nozzle Adapter
1
11-4
M29824
Nut, 14mm
1
11-5
HA3006
Nozzle
1
12
102801-01
Power Line RFI Filter
1
13
M30865-02
Bushing
2
14
M50400
Strain Relief Bushing
1
15
M30884
Fan
1
16
M50631
Rubber Bumper
2
17
101205-01
Motor Bracket
1
18
**
Motor and Pump Assembly
1
18-1
102001-15
Motor (230V/50Hz)
1
18-2
079975-03
Pump Body
1
18-3
M22009
Insert
1
18-4
M22456-2
Rotor
1
18-5
M29608
End Pump Cover
1
18-6
M29632
Lint Filter
1
18-7
M29633
Intake Filter
1
18-8
M29609
End Filter Cover
1
18-9
M12461-31
Screw, #10-32 x 1"
3
18-10 M8940
Steel Ball (1/4" Dia.)
1
18-11 M10993-1
Pressure Relief Spring
1
18-12 M27694
Adjusting Screw
1
18-13 M22997
Plug
1
18-14 M29612-01
Output Filter
1
18-15 M12461-32
Screw, #10-32 x 1 1/8"
6
18-16 M50016
Elbow, 90˚ (Barb Fitting)
1
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
PARTS LIST
35,000 Btu/Hr Model
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
**Not available as an assembly, order parts separately.
18-17 M8643-2
Blade
4
18-18 FHPF3-6C
Screw, #10-32 x 3/4"
2
19
M51105-01
Fan Guard
1
20
NTC-4C
Hex locknut
2
21
M50104-02
Bushing (wires)
2
22
102431-01
Screw/Lockwasher, 1/2"
11
23
098511-12
Lower Shell
1
24
M11271-8
Clip Nut
6
25
RF3-6B
Screw, #10-32 x 3/4"
1
26
M29652-04
Rubber Airline
1
27
M29652-05
Fuel Line
1
28
M16841-57
Wire Assembly (red)
1
29
M10990-3
Rubber Bushing
1
30
M50876-04
Fuel Filter Assembly
1
(Includes bushing)
31
102482-02
Electronic Ignitor
1
32
M11084-29
Screw, #10-16 x 3/4"
2
33
099125-13
Terminal Board
1
34
099157-01
Rivet
1
35
097630-02
Flame-Out Control
1
36
097702-01
Fuel Tank Cap
1
37
098513-89
Fuel Tank
1
38
097461-05AA
Side Cover
1
39
NPF-3B
Nut, #10-32
3
40
099177-01
Hex Nut
1
41
078918-01
Terminal Board Tab Cap
2
42
097785-01
Vinyl Foam Gasket
1
43
WLE-3
Lock Washer, #10
2
44
079010-33
Wire Assembly (black)
2
45
097462-01
ON/OFF Switch
1
46
079919-01
Switch Cover
1
PARTS AVAILABLE - NOT SHOWN
HA2210
Filler Neck Screen
1
097649-01
Tradename Decal
2
M9900-192
Combustion Chamber
Ground Wire
1
103666-01
Decal Package
1
