Dometic ECOVAC SANITATION SYSTEM - Manual (Page 2)

2
PRODUCT FEATURES
Dometic brings the technology, comfort and efficiency of EcoVac Sanitation Systems in an
easy-to-use and easy-to-maintain package.
• Freshwater Flush
• Eliminates the unpleasant sulfide odors which plague saltwater systems.
• Eliminates the need to draw flush water through the through-hull, seacock and vented loop.
• Significantly extends life of system components by eliminating salt water and impurities from
accumulating in the system over time.
•
Efficient Design
• Consumes a little over a pint of water per flush and allows boat owners to use a small waste tank.
The EcoVac system fills a 10-gallon tank in the same time that an electric toilet fills a 40-gallon
(113.6 liter) tank.
• Uses only 4-6 amps per flush on 12VDC.
•
Delightful Operation
• Simple one-lever flush control. No complex instructions needed.
• Comfortable adult-sized seat.
• Large water surface maintains clean bowl.
• Vitreous china bowl.
•
Reliability is Built-In
• USCG Certified Type III Marine Sanitation Device.
• No impellers or macerators – vacuum pump motor can run dry without burning up. No dynamic seals.
• Vacuum tank and vacuum generator design eliminates clogging problems associated with other
systems.
•
Dispose of Sewage Conveniently and Safely
• Toilet can be used without discharging sewage into sensitive waters.
• Holding tank discharge is at a dockside pump or at sea with optional overboard discharge.
• No portable toilet tanks to haul or dump.
•
Backed by the Best in Service and Quality
• The EcoVac system is from the leader in marine sanitation.
• Worldwide parts availability and technical backup.
TABLE OF CONTENTS
Dometic reserves the right to change specifications without notice.
Page Page
Vacuum Tester . . . . . . . . . . . . . . . . . . . . . . . 6
Service Tip . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting Guide . . . . . . . . . . . . . . . 7 - 9
Dimensional Specifications . . . . . . . . . . . . . 10
Parts Lists . . . . . . . . . . . . . . . . . . . . . . 10 - 13
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . 14
Parts Distributors . . . . . . . . . . . . . . . . . . . . 15
Manufacturer’s One-Year Limited Warranty 16 Product Features . . . . . . . . . . . . . . . . . . . . . 2
Key System Components . . . . . . . . . . . . . . . 3
Toilet Model Identification . . . . . . . . . . . . . . . . 4
Toilet Operation . . . . . . . . . . . . . . . . . . . . . . . 4
Proper Cleaning . . . . . . . . . . . . . . . . . . . . . . 5
Winterizing . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Convenience Products . . . . . . . . . . . . . . . . . 5
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ordering Parts . . . . . . . . . . . . . . . . . . . . . . . . 6
WARNING – HIGH VOLTAGE SYSTEM.
Turn off electrical power before servicing. WARNING – PUMP STARTS AUTOMATICALLY.
Turn off electrical power before servicing.
