Dometic ECOVAC SANITATION SYSTEM - Manual (Page 13)

13
PARTS LIST (cont’d)
VACUUM PUMP
VACUUM TANK
1
2
3
4
5
6
7
8
9
10
11
12
13
600340237
385640239
600341502
600342332
385310151
600340664
600343006
600347807
600347802
385310076
600347801
600341489
385230980
Cover Screw, #4 x 3/8" Pan Hd SS
Pump Cover
Top Closure
Hex Head Screw, #10-32 x ½" SS
O-Ring Replacement Kit
Bushing, Bellows
Hex Head Shoulder Screw, Brass
Bellows Clamp
Valve Nipple
1 ½" Duckbill Valve
Valve Adapter
Pump Body
Bellows Assembly (includes item 6)
14
15
16
16A
17
-
Set Screw, ¼ -28 x 5/16"
Eccentric
12VDC Motor Kit
24VDC Motor Kit
Hex Washer Head Screw #10-12 x 7/8" SS
Not Shown
Pump Assembly, less motor (includes items 3, 5,
6, 8 - 13)
Item Part No. Description Part No. Item Description
VACUUM PUMP
VACUUM TANK
1
2
3
4
5
6
7
Insert Adapter
Street Elbow
Vacuum Switch Cover
Vacuum Switch Assembly
Snap Lock Clamp
Mounting Bracket
Vacuum Tank Kit (includes 2 ea. Item 1 and 1 ea. Item 2)
307341513
307341161
600348037
385318032
600346835
600348361
385310017
Item Part No. Description
600347788
600344470
385310245
385310246
600341503
385310249
