21
© 2001 Directed Electronics, Inc.
WIRING CONNECTIONS
1.
Audio/video outputs for the amplifier and
monitor.
2.
Inputs for a second audio/video source
(i.e., headunit, VCP, or video game).
3.
Port for an external IR sensor. This allows
the same functions as the IR sensor on the
main unit but from a remote location.
4.
Power wire:
a.
RED - Connect this wire to a power
source that shows (+) 12 volts when
the key is in the accessory position.
b.
YELLOW - Connect this wire to a (+)
12 volt constant power source.
c.
BLACK - Connect this wire to a
quality chassis ground, preferably
scraped sheet metal.
Wiring Guide
TO POWER SUPPLY
M
E
M
O
R
Y
B
A
C
K
-U
P
G
R
O
U
N
D
(B
-)
IG
N
IT
IO
N
S
W
IT
C
H
(B
+)
B
LA
C
K
Y
E
LL
O
W
R
E
D
(VIEW FROM REAR)
DVD MAIN UNIT
TO
TV
TO AMPLIFIER
YE
LL
OW
RE
D
WH
ITE
Vid
eo
IN
AV signal IN
YE
LL
OW
RE
D
WH
ITE
(L)
( )
R
(L)
( )
R
