27" Wide Models Dryer Dimensions
Front View
1
/
2
"
(13 mm)
27"
(686 mm)
43"
(1092 mm)
A
B
A. Wide opening side-swing door
B. Wide opening hamper door
Side View
22
3
/
4
"
(578 mm)
13
3
/
4
"
(349 mm)
29
1
/
2
"
(749 mm)
29
1
/
2
"
(749 mm)
Back View
Non-Steam
Installation Spacing
3"*
(76 mm)
3"*
(76 mm)
24 in.
2
*
(155 cm
2
)
48 in.
2
*
(310 cm
2
)
18"*
(457 mm)
1"*
(25 mm)
1"*
(25 mm)
5
1
/
2
"*
(140 mm)
14"* max.
(356 mm)
*Required spacing
Installation spacing for recessed area or closet
The dimensions shown are for the minimum spacing allowed.
■
Additional spacing should be considered for ease of installation and servicing.
■
Additional clearances might be required for wall, door, and floor moldings.
■
Additional spacing of 1" (25 mm) on all sides of the dryer is recommended to reduce noise transfer.
■
For closet installation, with a door, minimum ventilation openings in the top and bottom of the door are
required. Louvered doors with equivalent ventilation openings are acceptable.
■
Companion appliance spacing should also be considered.
14"
(356 mm)
3
3
/
8
"
(85 mm)
