8
Press AUDIO momentarily to select between Volume
(default), Bass, Treble, Balance, Fader & Subwoofer.
Press AUDIO until BAS appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until TRE appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until BAL appears then rotate encoder
left/right to adjust (BAL L 12-BAL 00-BAL R 12).
BAL 00 represents equal balance
Press AUDIO until FAD appears then rotate encoder
left/right to adjust (FAD F 12-FAD 00-FAD R 12).
FAD 00 represents equal fader
Press AUDIO until SUB appears then rotate encoder
left/right to adjust (SUB 00-SUB 12).
Individual Bass and Treble settings are retained in memory
for AM, FM, CD, and AUX modes. This allows you to save the
Bass and Treble settings separately for each mode.
Example:
FM tuner mode can have Bass +3 and Treble -1 while CD
mode can have Bass +2 and Treble +2.
Note:
Any adjustment to the Bass or Treble settings automatically
cancels the current EQ curve (if one is selected).
Press RESET upon initial installation or if abnormal
operation occurs. Refer to page 4 for the reset button
location.
Audio
Bass
Treble
Balance
Fader
Subwoofer
Source Audio Memory
Reset
XDM7610 OPERATION
General Operation - Audio Settings
BASS VOLUME TREBLE BALANCE FADER SUBWOOFER
