6
The front panel is semi-permanently attached during
assembly. Please refer to the separate yellow instructions
(before installation) to make the front panel removable.
With the unit off, press OPEN to allow the front panel to slide
down. Gently squeeze the release tab located on the bottom
center underside and pull front panel down and away from
unit to remove. To install, insert left side first, then push right
side to secure.
Press POWER or any other button (except EJECT or OPEN)
to turn the unit on. Inserting a disc will turn the unit on
automatically. Press POWER to turn the unit off.
Press MODE to select between tuner, CD player and auxiliary
input. Modes of operation are indicated in the display.
Adjust volume using rotary encoder (00-46).
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Press and hold POWER for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
Press DISP to select between clock and radio frequency
(tuner mode), clock and CD track/elapsed time (CD mode), or
clock and AUX (AUX mode).
With the unit on, press and hold DISP until the clock begins to
flash, then release. Press TUNE
nn to adjust the hours and
TUNE
ll
to adjust the minutes. Press DISP momentarily to
save the selected time.
The clock will display 12-hour AM/PM time in USA frequency
spacing mode (PM 10:00). In European frequency spacing
mode, the clock will display 24-hour time (22:00).
Front Panel Note:
Front Panel Removal
Power On/Off
Mode
Volume
Mute
Programmable
Turn-On Volume
Preset EQ Curves
Display
Set the Clock
12/24-hour Clock
XDM7610 OPERATION
General Operation
