www.desatech.com 110021-01H 39
PARTS LIST
REMOTE-READY MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 40 of this manual.
PART NUMBER
KEY VRL24NR VRL24PR CSG3930NR CSG3930PR
NO. CSG3924NR VRL30NR CSG3924PR VRL30PR CTB3924NR CTB3924PR DESCRIPTION QTY
1 ** ** ** ** ** ** Burner Carriage 1
2 110328-01 110328-01 110061-03 110061-03 110328-01 110061-03 Tube, Front and Rear Burner 1
3 110061-01 110061-01 110061-01 110061-01 110061-01 110061-01 Tube, Middle Burner Remote 1
4 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 Retainer Spring 1
5 110063-02 110063-02 110063-02 110063-02 ____ ____ Burner, Front Blue Flame 1
____ ____ ____ ____ 110063-03 110063-03 Burner, Front Yellow Flame 1
6 110063-01 110063-01 110063-01 110063-01 110063-01 110063-01 Burner, Middle Blue Flame 1
7 108105-01 108105-01 108105-01 108105-01 108105-01 108105-01 Burner, Rear 1
8 107110-01 107110-01 107110-01 107110-01 107110-01 107110-01 Spacer 2
9 103779-01 103779-01 103778-01 103778-01 103779-01 103778-01 ODS Pilot 1
10 108135-01 108135-01 108135-01 108135-01 108135-01 108135-01 Valve Bracket 1
11 099387-14 099387-14 099387-09 099387-09 099387-14 099387-09 Pilot Tube 1
12 099387-15 099387-15 ____ ____ 099387-15 ____ Pilot Regulator Tube, NG 1
13 110093-04 110093-04 110093-04 110093-04 110093-04 110093-04 Pilot Mounting Bracket 1
14 097159-04 097159-04 097159-04 097159-04 097159-04 097159-04 Piezo Ignitor 1
15 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
16 099056-18 099056-18 099056-21 099056-21 099056-18 099056-21 Burner Orifice Injector Back 1
17 101004-02 101004-02 101004-18 101004-18 101004-02 101004-18 Burner Orifice Injector Front 1
18 101004-11 101004-11 101004-13 101004-13 101004-11 101004-13 Burner Orifice Injector Middle 1
19 108692-04 108692-04 108692-04 108692-04 108692-04 108692-04 Remote Cover Plate
1
20 098265-02 098265-02 098265-02 098265-02 098265-02 098265-02 Male Elbow 1
21 M12461-26 M12461-26 M12461-26 M12461-26 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
22 099918-02 099918-02 ____
____ 099918-02 ____ Pilot Regulator, NG 1
23 103781-03 103781-03 103781-04 103781-04 103781-03 103781-04 Gas Control Valve 1
24 108106-01 108106-01 108106-01 108106-01 108106-01 108106-01 Manual Control Valve 1
25 099393-03 099393-03 099393-03 099393-03 099393-03 099393-03 Control Knob 1
26 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1
27 103284-03 103284-03 103284-03 103284-03 103284-03 103284-03 Wire Harness 1
28 108111-01 108111-01 108111-01 108111-01 108111-01 108111-01 Cast Iron Grate 1
29 103587-02 103587-02 103587-02 103587-02 103587-02 103587-02 Plate, Switch 1
30 099998-01 099998-01 099998-01 099998-01 099998-01 099998-01 Fan Switch 1
31 103784-01 103784-01 103784-01 103784-01 103784-01 103784-01 On-Off-Pilot Knob Extension 1
32 108631-01 108631-01 108631-01 108631-01 108631-01 108631-01 Log Alignment Screw 8
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1
103877-04 103877-04 103877-04 103877-04 103877-04 103877-04 Lighting Instructions Plate 1
100639-03 100639-03 100639-03 100639-03 100639-03 100639-03 Caution Decal 1
GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1
** Not a field replaceable part
