PARTS LIST
THERMOSTAT-CONTROLLED MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 40 of this manual.
PART NUMBER
KEY VRL24NT
VRL24PT
NO. CSG3924NT CSG3924PT VRL30NT
VRL30PT
CTB3924NT CTB3924PT DESCRIPTION
QTY
1
**
**
**
**
**
**
Burner Carriage
1
2
110328-01 110061-03 110328-01 110061-03 110328-01 110061-03 Tube, Front and Rear Burner 1
3
110061-02 110061-02 110061-02 110061-02 110061-02 110061-02 Tube, Middle Burner T-Stat 1
4
111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 Retainer Spring
1
5
110063-02 110063-02 110063-02 110063-02 ____
____ Burner, Front Blue Flame
1
____ ____ ____ ____ 110063-03 110063-03 Burner, Front Yellow Flame 1
6
110063-01 110063-01 110063-01 110063-01 110063-01 110063-01 Burner, Middle Blue Flame 1
7
108105-01 108105-01 108105-01 108105-01 108105-01 108105-01 Burner, Rear
1
8
107110-01 107110-01 107110-01 107110-01 107110-01 107110-01 Spacer
2
9
107485-01 104286-01 107485-01 104286-01 107485-01 104286-01 ODS Pilot
1
10 102394-02 102394-02 102394-02 102394-02 102394-02 102394-02 Control Bracket (T-Stat)
1
11 099387-09 099387-09 099387-09 099387-09 099387-09 099387-09 Pilot Tube
1
12 108628-01 108628-01 108628-01 108628-01 108628-01 108628-01 Inlet Tube
1
13 110093-04 110093-04 110093-04 110093-04 110093-04 110093-04 Pilot Mounting Bracket
1
14 097159-04 097159-04 097159-04 097159-04 097159-04 097159-04 Piezo Ignitor
1
15 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable
1
16 099056-18 099056-21 099056-18 099056-21 099056-18 099056-21 Burner Orifice Injector, Back 1
17 101004-02 101004-18 101004-02 101004-18 101004-02 101004-18 Burner Orifice Injector, Front 1
18 101004-11 101004-13 101004-11 101004-13 101004-11 101004-13 Burner Orifice Injector, Middle 1
19 108692-02 108692-02 108692-02 108692-02 108692-02 108692-02 T-Stat Cover Plate
1
20 108692-03 108692-03 108692-03 108692-03 108692-03 108692-03 Remote Cover Plate
1
21 102030-01 102030-01 102030-01 102030-01 102030-01 102030-01 Thermobulb Clip
2
22 098867-16 098867-16 ___
098867-16 ___
098867-16 Gas Regulator (Propane/LP) 1
___
___
098867-15 ___
098867-15 ___
Gas Regulator (Natural)
1
23 098522-25 098522-10 098522-25 098522-10 098522-25 098522-10 Thermostatic Gas Valve Kit 1
24 108106-01 108106-01 108106-01 108106-01 108106-01 108106-01 Manual Control Valve
1
25 099393-03 099393-03 099393-03 099393-03 099393-03 099393-03 Control Knob
1
26 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut
1
27 108631-01 108631-01 108631-01 108631-01 108631-01 108631-01 Log Alignment Screw
8
28 108111-01 108111-01 108111-01 108111-01 108111-01 108111-01 Cast Iron Grate
1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate
1
101054-05 101054-05 101054-05 101054-05 101054-05 101054-05 Lighting Instructions Plate
1
100639-03 100639-03 100639-03 100639-03 100639-03 100639-03 Caution Decal
1
GA6060
GA6060
GA6060
GA6060
GA6060
GA6060
Lava Rock
1
** Not a field replaceable part
