PANEL
06
REAR PANEL OUTPUT
FRONT PANEL
1. 2 CHANNELS OUTPUT
2. S-VIDEO OUTPUT
3. COAXIAL OUTPUT
4. VIDEO OUTPUT
5. Y, CB/PB, CR/PR OUTPUT
2 1 4 3 5
COAXIAL
S-VIDEO
VIDEO
DIGITAL AUDIO OUT L
R
110V-240V~ 50/60Hz
C R /P R
Y C B /P B
CLASS 1 LASER PRODUCT
2-CH AUDIO OUT VIDEO OUT VIDEO OUT
Manufactured under license from
Dolby Laboratories."Dolby", and
the double-D symbol are tradem-
arks of Dolby Laboratories.
Confidential Unpublished works.
Copyright 1992-1997 Dolby Lab-
oratories. All rights reserved.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION Tested To Comply
With FCC Standards
For Home or Office Use
POWER: 15W S/N:
MODEL:D S-5701 AC: 110V-240V~ 50/60Hz
DVD PLAYER
PRODUCT IS CERTIFIED BY
THE MANUFACTURER TO
COMPLY WITH DHHS RUL-
ES21 CFR, SUBCHAPTER
J APPLICABLE AT THE
DATA OF MANUFACTURE
Apparatus Claims
of U.S. Patent
Nos. 4,631,603;
4,577,216; 4,819,098
and 4,907,093
licensed for limited
viewing uses only.
OPEN/CLOSE PLAY/PAUSE
DVD/CD/MP3/CD-R/CD-RW/JPEG/KODAK PICTURE CD PLAYER
STOP POWER ON
OFF
DS-5701
1. REMOTE CONTROL SENSOR
2. TRAY
3. OPEN/CLOSE
4. PLAY/PAUSE
5. STOP
6. POWER SWITCH
1 2 3 4 5 6
