Directed Video HVM580 User Manual

Page 6

IInnssttaallllaattiioonn—

—PPeeddeessttaall M

Moouunntt ((O

Oppttiioonnaall))

1. Slide monitor onto the pedestal mount and then tighten using fastener (the

pedestal mount is optional).

2. Firmly attach dash mount on a flat surface and adjust viewing angle of moni-

tor by tightening the viewing angle knob at the side.

VIEWING ANGLE

KNOB LOCK

LCD

SCREEN

MOUNTING PEDESTAL

(OPTIONAL)

PEDESTAL

MOUNT

(OPTIONAL)

LCD SCREEN

(REAR)
