Durabrand Color Television Receiver DBTV2500 - Manual (Page 30)

ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION
MISCELLANEOUS
CP806 069W010010 CONNECTOR PCB SIDE 005P-2100
CP802A 067R005019 WIRE HOLDER 51048-0510
CP802B 067R005019 WIRE HOLDER 51048-0510
CP803A 067R104019 WIRE HOLDER 51052-0400
CP803B 067R104019 WIRE HOLDER 51052-0400
! DY801 027M062505 DY 7M062505
! F501 081PA6R302 FUSE 23706.3
! FB401 043225010F TRANSFORMER, FLYBACK 3225010F
FH501 06710T0006 HOLDER, FUSE EYF-52BC
FH502 06710T0006 HOLDER, FUSE EYF-52BC
! K001 129A000010 WEDGE 8115529
! K002 129A000010 WEDGE 8115529
! K003 129A000010 WEDGE 8115529
MG801 026A062704 MAGNET, CONVERGENCE 29MMSTAR
MS501 128B000018 SHEET 23MICA
OS101 077Q014003 REMOTE RECEIVER PIC-28143SY-2
! RY101 0560V20115 RELAY ALKS321
! SP351 070C533016 SPEAKER SA04A05AWA
! TH501 DF40A3R0Q0 DEGAUSS, ELEMENT PTAD14K2-3R0Q141
TM101 076R074180 TRANSMITTER R25-1127
! TU001 0145W00049 TUNER, VHF-UHF NJH3021U268
! V801 0984250502 COLOR, PICTURE TUBE A63AHC26X
X101 1002T00801 CERAMIC OSILLATOR 8MHz
X602 100CT3R505 CRYSTAL HC-49/C 3.579545MHz
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP................. POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP................. METAL POLYESTER CAPACITOR
CMPL............... METAL PLASTIC CAPACITOR
CMPP.............. METAL POLYPROPYLENE CAPACITOR
J 2 - 2
