OPTION – DIM OUT
The dim out option allows the dim output to be turned on or off. The dim output is used if you have installed other Dakota
Digital gauges and would like this gauge to also control the dimming of these gauges. If the dim out option is turned on,
12v is sent out on the dim out wire when the gauge is dimming. In this mode, the gauge will be either in dim mode or full
brightness mode.
If no other gauges are to be dimmed, this option can be set to off. In this mode the gauge will fade when dimming and
gauge dimming will be less noticeable.

TROUBLESHOOTING

PROBLEM

CAUSE

SOLUTION

Gauge does not light up

Gauge has bad ground or power

Check connections to wiring harness and check
wiring harness and gauge wires for pinched or
broken wires.

Speed reads incorrectly

Speedometer needs to be recalibrated

See setup for speed calibration instructions.

Gauge does not dim

Dim level is set to off or set too low

Set dim level to higher level (see setup)

Gauge is always dim

Dim level is set too high
Light sensor over left switch is covered

Set dim level to lower level (see setup)
Make sure left side of lens is not covered.

 is displayed in fuel or
oil display

No sender connected.

Check proper connection to sender. Check for
broken or pinched sensor wires.

 is displayed in fuel or
oil display.

Sensor wire is shorted to ground.

Check sensor wire harness for correct connection
to sensor. Check for pinched or broken sensor
wire harness.

SERVICE DUE is scrolled
in the message center

One of the countdown service meters
has reached zero

Perform service and reset service meter by
holding right switch when service meter is
displayed. If service meter operation is not
desired, disable service meter by setting to

 in

the setup menu.

ERR 01 to ERR 99 is
displayed in the message
center

The Rhino engine computer is sending
error codes to the gauge.

See your Yamaha dealer for appropriate service.

ERR B.1 is displayed in
message center

Gauge has poor bus connection to
Rhino engine computer.

Check for good connection to gauge harness.

ERR B.2 is displayed in
message center

Bus wire is always in high state.

Gauge bus circuit damaged.

Check for shorts to 12V on bus wire.

Repair needed.

ERR B.3 is displayed in
message center

Bus wire is shorted to ground.

Check for shorts to ground on bus wire. Check for
proper connection to Rhino harness.


GAUGE WIRE COLOR CHART

VIOLET / BLACK

Data bus

BLACK / RED

Keyed power

WHITE / BLUE

Ground

WHITE

Fuel sender

GREEN / BLUE

Constant power
