© 2003 ITW Finishing Systems and Products
5
Specification
E E Patent No 2372465 (GB)
Air supply connection - Universal 1 /
4
“ BSP and NPS
Fluid Supply Connection - Universal 3 /
8
“ BSP and NPS
Maximum static Air inlet pressure - P
1
= 12 bar (175 psi)
Maximum static Fluid inlet pressure - P
2
= 15 bar (218 psi)
Nominal gun Air inlet pressure -
with gun triggered 3.0 bar (44 psi)
Maximum Service temperature 40°C
Gun Weight - 435 g
Materials of Construction
Gun body Aluminium
Nozzle Stainless Steel
Needle Stainless Steel
Fluid Inlet Stainless Steel / PTFE
Trigger Nickel Plated Steel
