Control elements – LD Systems STINGER SUB 15 A G2 User Manual
Page 12
1
LINE INPUT
Balanced line input (left/right) XLR/ 6,3 mm jack
(combo).
2
SUB LEVEL
Subwoofer volume.
3
SUB PHASE
Inverts the phase of the subwoofer (0° / 180°)
if necessary.
4
SUB FREQ
Adjusts the upper cut-off frequency of the
subwoofer (80 - 200 Hz Low-Pass).
5
LINE DIRECT OUTPUT (LEFT/RIGHT)
Balanced XLR line output (left/right).
6
SAT OUTPUT 100Hz (LEFT/RIGHT)
Balanced XLR line output with 100 Hz High-Pass
for active satellites or power amplifiers.
7
POWER LED
8
SIGNAL LED
Lights up when the unit receives an audio
signal.
9
LIMIT LED
Lights up when the limiter is active. The limiter
function protects your subwoofer from damage.
If the limiter LED lights up permanently, reduce
volume.
10
PROTECT LED
LED lights up, when the active subwoofer
is overloaded. The subwoofer automatically
switches to mute.
11
POWER
Switches power on/off.
12
MAINS SOCKET (VOLEX POWER PLUG)
Lockable power input socket with built-in fuse
holder (Fuse T6.3AL / 250 V AC).
13
MAINS THROUGH
Lockable power output socket. Supplies other
units, e.g. active subwoofers or active subwoofers
or active satellite speakers.
14
SPEAKER OUT
Speakon compatible subwoofer output. Only con-
nect passive 8Ω subwoofers, e.g. LDESUB15G².
