CERTIFIED INSTALLATION
Certified installations require one roof vent and one lower side
vent or as optional one upper vent and one lower side vent
The two alternatives are provided for by using the drfferent kits
listed in the Appendix.
For further information contact your dealer or distributor.
METHODS OF INSTALLATION
The methods of installation are shown in figures 10 a and 10 b.
It is essential that all maximum or minimum dimensions are ventilation
strictly maintained as the performance of the refrigerator is height
dependent on an adequate flow of air over the rear of the
refrigerator.
VENTILATION HEIGHTS
Refrigerator
model Minimum ventilation heights in inches and mm
Installation with Installation with roof
upper and lower vent and lower side
l side vent vent Fig. 10 a
RM 37
940
RM
_ 34
864
RM2501 42
_
m m 1067
RM
56
_
1422
- 62
1575
Duct cross
section
Ventilation
height
area 5" x 18"
Condenser
Fig. 10 b
