3
LOW BATTERY
• When this low battery icon appears in the indoor (IN) reading section,
replace the batteries in the weather station.
• When this low battery icon appears in the outdoor (OUT) readings
section, replace the batteries in the outdoor transmitter.
POSITION THE WEATHER STATION
Choose a location for the weather station that is within range (200 feet, 60
meters) of the outdoor transmitter. The weather station has a build in base
stand to sit on a table or desk.
• Choose a location 6 feet or more from electronics such as
cordless phones, gaming systems, televisions, microwaves,
routers, baby monitors, etc., which can prevent signal
reception.
• Be aware of electrical wires and plumbing within a wall.
• Best reception is achieved when the front or the back of the
weather station is facing the outdoor transmitter. This allows
a larger portion of the antenna to receive a signal.
POSITION THE WIRELESS OUTDOOR TRANSMITTER
Once the weather station shows the outdoor temperature/humidity, place it
and the transmitter in the desired locations and wait approximately one hour
before permanently mounting the transmitter to ensure that there is proper
reception. The transmitter should be mounted vertically, in a shaded,
protected area, at least 6 feet from the ground to avoid damage and ensure
accurate readings. The transmitter is water resistant, not waterproof and
should not be placed anywhere it will become submerged in water or
subject to standing water or snow.
Choose a location for the transmitter that is within range of
the Weather station and under an overhang for accuracy.
The maximum transmitting range in open air is over 200-feet
(60 meters).
Option 1:
• Install one mounting screw (not included) into a wall
leaving approximately ½ of an inch (12.7mm) extended.
• Place the transmitter onto the screw, using the hanging
hole on the backside.
• Gently pull the transmitter down to lock the screw into
place.
Option 2:
• Insert the mounting screw (not included) through the front of the
transmitter and into the wall.
• Tighten the screw to snug (do not over tighten).
To achieve a true temperature/humidity reading, mount where direct
sunlight cannot reach the outdoor transmitter. Mount the outdoor
transmitter on a North-facing wall or in any well shaded area. Under an
eave or deck rail work well. The maximum transmitting range in open air is
over 200-feet (60 meters). Obstacles such as walls, windows, stucco,
concrete, and large metal objects can reduce the range. Place the
transmitter at least 6 feet in the air to improve signal transmission.
CARE AND MAINTENANCE
• Do Not Mix Old and New Batteries
• Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries
• Do not expose the weather station to extreme temperatures, vibration or
shock.
• Keep weather station dry.
• Clean weather station with a soft damp cloth. Do not use solvents or
scouring agents.
• The weather station is not a toy. Keep it out of reach of children.
• The weather station is not to be used for medical purpose or for public
information; it is for home use only.
• The specifications of this weather station may change without prior notice.
• Improper use or unauthorized opening of housing will void the warranty.
• If the weather station does not work properly, change the batteries.
SPECIFICATION
Indoor:
Temperature Range:
+32°F to +122°F (0°C to 50°C)
Interval: About every 30 seconds
Outdoor:
Temperature Range:
-40°F to 140°F (-40°C to 60°C)
Distance: Over 200 ft. (60 meters)
RF 433MHz (open air)
Interval: About every 50 seconds
Power:
Weather Station:
2-AA, IEC, LR6 batteries (not included)
TX141TH-A Transmitter: 2-AA, IEC, LR6 batteries (not included)
Battery Life:
TX141TH-A Transmitter
Battery Life: Battery life is over 24 months when
using reputable Alkaline battery brands.
Weather Station
Battery Life:
Battery life is over 12 months when
using reputable Alkaline battery brands.
Dimensions:
Weather Station:
5.40” L x 1.68” W x 4.40” H
(137.2 mm L x 42.8 mm W x 111.8 mm H)
TX141TH-A Transmitter:
1.57" L x 0.79" W x 5.12" H
(40 x 20 x 130 mm)
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year limited warranty on this
product against manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only
on products purchased and used in North America and only to the original
purchaser of this product. To receive warranty service, the purchaser must
contact La Crosse Technology, Ltd for problem determination and service
procedures. Warranty service can only be performed by a La Crosse
Technology, Ltd authorized service center. The original dated bill of sale
must be presented upon request as proof of purchase to La Crosse
Technology, Ltd or La Crosse Technology, Ltd’s authorized service center.
La Crosse Technology, Ltd will repair or replace this product, at our option
and at no charge as stipulated herein, with new or reconditioned parts or
products if found to be defective during the limited warranty period specified
above. All replaced parts and products become the property of La Crosse
Technology, Ltd and must be returned to La Crosse Technology, Ltd.
Replacement parts and products assume the remaining original warranty,
or ninety (90) days, whichever is longer. La Crosse Technology, Ltd will
pay all expenses for labor and materials for all repairs covered by this
warranty. If necessary repairs are not covered by this warranty, or if a
product is examined which is not in need or repair, you will be charged for
the repairs or examination. The owner must pay any shipping charges
incurred in getting the La Crosse Technology, Ltd product to a La Crosse
Technology, Ltd authorized service center. La Crosse Technology, Ltd will
pay ground return shipping charges to the owner of the product to a USA
address only.
The La Crosse Technology, Ltd warranty covers all defects in material and
workmanship with the following specified exceptions: (1) damage caused by
accident, unreasonable use or neglect (including the lack of reasonable and
necessary maintenance); (2) damage occurring during shipment (claims
must be presented to the carrier); (3) damage to, or deterioration of, any
accessory or decorative surface; (4) damage resulting from failure to follow
instructions contained in the owner’s manual; (5) damage resulting from the
performance of repairs or alterations by someone other than an authorized
La Crosse Technology, Ltd authorized service center; (6) units used for
other than home use (7) applications and uses that this product was not
intended or (8) the products inability to receive a signal due to any source of
interference.
This warranty covers only actual defects within the product itself, and does
not cover the cost of installation or removal from a fixed installation, normal
set-up or adjustments, claims based on misrepresentation by the seller or
performance variations resulting from installation-related circumstances.
