13 102569
OWNER’S MANUAL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098511-208 Upper Shell (Yellow) 1
098511-209 Upper Shell (White) 1
098511-229 Upper Shell (Black) 1
2 100647-01 Screw, #10-16 x 1/2" 8
3 098512-48 Combustion Chamber
4 099229-01 Photocell Bracket 1
5 M10908-2 Screw, #6-32 x 3/8" 2
6 HA3019 Photocell Assembly 1
7 *** Burner Head Assembly 1
7-1 100735-13 Nozzle 1
7-2 M10659-1 Nozzle Washer 2
7-3 M10809-1 Nozzle Spring 1
7-4 M8882 Nozzle Sleeve 1
7-5 M50924-08 Burner Head Body 1
7-6 M50820-02 Barb Fitting 2
7-7 HA3012 Spark Plug 1
7-8 103409-01 Washer, Wave Spring 1
8 M11084-27 Screw, #10-16 x 1/2" 3
9 102042-01 Fan 1
10 *** Motor and Pump Assembly 1
10-1 102001-07 Motor 1
10-2 079975-03 Pump Body 1
10-3 FHPF3-6C Screw, #10-32 x 5/8" 2
10-4 M22009** Rotor Insert 1
10-5 M22456-2** Pump Rotor 1
10-6 M50545 Pump End Cover 1
10-7 M12179** Intake Filter 1
10-8 M16545-02 Filter End Cover 1
10-9 M8940** Steel Ball, 1/4" Diameter 1
10-10 M10993-1** Relief Spring 1
10-11 M27694** Adjusting Screw 1
10-12 M22997** Plug 1
10-13 M12461-31 Screw, #10-32 x 1" 4
10-14 M12244-1** Output Filter 1
10-15 M11637** Lint Filter 1
10-16 M50820-02 Barb Fitting 1
10-17 M8643-2** Blade 4
10-18 M12461-32 Screw, #10-32 x 1.12" 6
11 M50631 Rubber Bumper 2
12 101206-01 Motor Mounting Bracket 1
13 097061-01 Solid State Relay 1
14 M15823-39 Screw, #8-18 x 1/2" 2
15 NTC-4C Hex Lock Nut, 1/4-20 2
16 102756-01 Fan Guard 1
17 102482-01 Ignitor Kit 1
18 M11084-29 Screw, #10-16 x 3/4" 2
19 M51345-03 Fuel Line 1
PARTS LIST
B200, R200, REM200
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the correct
model and serial numbers (from the model plate), then the part number and description of the desired part.
KEY PART
NO. NUMBER DESCRIPTION QTY.
** See OPTIONAL ACCESSORIES *** Not available as an assembly.
20 M51150-01** Fuel Filter 1
21 M51345-04 Fuel Line Tube 1
22 M10990-3 Rubber Bushing 1
23 M50814-03 Airline 1
24 098511-210 Lower Shell (Yellow) 1
098511-211 Lower Shell (White) 1
098511-230 Lower Shell (Black) 1
25 M50104-03 Bushing 2
26 M50104-01 Bushing 2
27 M11084-27 Screw, #10-16 x 1/2" 6
28 M11271-8 Clip Nut 8
29 M10908-14 Screw, #8-32 x 3/8" 1
30 098513-86 Fuel Tank 1
31 097702-01 Fuel Cap (Includes Gasket) 1
32 HA3003 Flame-out Control 1
33 M11143-1 Strain Relief Bushing 1
34 098219-19 Power Cord 1
35 102562-01AA Side Cover 1
36 M11084-27 Screw, #10-16 x 1/2" 4
37 099125-12 Terminal Board 1
38 099157-01 Rivet 1
39 079010-20 Wire Assembly (Red, 18") 1
40 M16841-57 Wire Assembly (Red, 6") 1
41 M27417 Drain Plug (Includes “o” Ring) 1
42 099177-01 Hex Nut, 3/8 - 27 1
43 103523-01 Rubber Bushing 1
44 *** Fuel Valve Assembly 1
44-1 105939-01 Fuel Valve 1
44-2 103129-01 Fuel Valve Bracket 1
44-3 M12461-13 Hex Head Screw, 8-32 x 1/4" 2
44-4 M50820-02 Fitting Barb 2
44-5 M11084-38 Hex TPG Screw, 8-18 x 3/8" 2
44-6 WLE-2 Lockwasher 2
44-7 079010-31 Wire Assembly, Red 1
44-8 079010-32 Wire Assembly, White 1
45 097785-04 Foam Gasket 2
46 099230-01 Screw, Special 2
47 M11084-27 Screw, #10-16 x 1/2" 2
OPTIONAL ACCESSORIES
HA1210 Hang-up Thermostat 1
HA1180 Air Gauge Kit 1
HA2210 Fuel Tank Filter Screen 1
HA3005 Rotor Kit (M22456-2, M22009,
M8643-2)
1
HA3017 Filter Kit (M11637, M12179,
M12244-1, M51150-01)
1
HA3020 Pump Kit (M27694, M10993-1,
M22997, M8940)
1
