DUCANE
SUPPLY AND
MODEL
UNIT DIMENSIONS
RETURN DUCT
FLUE
OVERALL
BLOWER
NUMBER
LENGTH
WIDTH
HEIGHT
OPENINGS
DIA.
DIMENSIONS
DOOR
A
B
C
D
E
F
G
H
FPBB050A3B
50
13 1/2
23 1/8
11 5/8
21 3/8
4
19 1/2
FLUSH
8.3
112
FPBB075A3B
50
13 1/2
23 1/8
11 5/8
21 3/8
4
19 1/2
FLUSH
9.9
121
FPBB075A4B
50
13 1/2
23 1/8
11 5/8
21 3/8
4
19 1/2
1
11.7
121
FPBB100A4B
50
17
23 1/8
15 1/8
21 3/8
4
23
FLUSH
9.9
141
FPBB100A5B
50
17
23 1/8
15 1/8
21 3/8
4
23
1
13.1
141
FPBB125A5B
50
20 1/2
23 1/8
18 5/8
21 3/8
4
26 1/2
FLUSH
11.7
161
NOTE: Dimensions are in inches
GENERAL LAYOUT
B D
H
G
F
A
E C
DUE TO OUR POLICY OF CONTINUOUS IMPROVEMENT,
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Printed on recycled paper
09/02 30K
www.ducanehvac.com
For more information, contact your local Ducane distributor.
T H E D I F F E R E N C E I S Q U A L I T Y. ™
20590902
replaces 20091122
MAX. UNIT
AMPS
UNIT WT.
LBS.
