FPBB050A3B FPBB075A3B FPBB100A4B FPBB125A5B
GAS NATURAL (LP with conversion kit)
INPUT RATE (BTU per Hour) 50,000 75,000 100,000 125,000
HEATING CAPACITY (BTU per Hour) 40,000 61,000 81,000 101,000
AFUE (ISOLATED COMB. SYSTEM) 80%
TEMPERATURE RISE 30 - 60 F 40 - 70 F
VOLTS / PHASE / HERTZ 115 /1/ 60
STATIC PRESSURE (CERTIFIED MAX) 0.50" W.C.
BLOWER MOTOR HORSEPOWER 1/3 1/2 3/4
BLOWER WHEEL (DIA. X WIDTH) 10 x 6 12 x 9 12 x 12
NUMBER OF HEAT EXCHANGERS 2 3 4 5
LIMIT CONTROL, SNAP DISK STYLE 150 F 170 F 170 F 150 F
IGNITION CONTROL DIRECT SPARK
TRANSFORMER 40 VA, 115VAC PRIMARY, 24VAC SECONDARY, FOOT-MOUNTED
INTEGRATED CONTROL SYSTEM INTEGRATED FURNACE CONTROL
SHIPPING DIMENSIONS 54 X 26 X 25 3/4 54 X 29 X 25 3/4 54 X 33 X 25 3/4
SHIPPING WEIGHT 144 153 175 197
MAXIMUM DESIGN OUTLET TEMP. 170 F
AUXILIARY LIMIT 130 F 140 F
UNIT SPECIFICATIONS
HORIZONTAL 80
TM
D u c a n e G a s F u r n a c e
FPBB075A4B FPBB100A5B
GAS NATURAL
INPUT RATE (BTU per Hour) 75,000 100,000
HEATING CAPACITY (BTU per Hour) 61,000 81,000
AFUE (ISOLATED COMB. SYSTEM) 80%
TEMPERATURE RISE 30 - 60 F
VOLTS/PHASE/HERTZ 115/1/60
STATIC PRESSURE (CERTIFIED MAX) 0.50 "W.C.
BLOWER MOTOR HORSEPOWER 1/2 3/4
BLOWER WHEEL (DIA. X WIDTH) 10 X 6 12 X 9
NUMBER OF HEAT EXCHANGERS 3 4
LIMIT CONTROL, SNAP DISK STYLE 170 F 160 F
IGNITION CONTROL DIRECT SPARK
TRANSFORMER 40 VA. 115VAC PRIMARY, 24VAC SECONDARY, FOOT-MOUNTED
INTEGRATED CONTROL SYSTEM INTEGRATED FURNACE CONTROL
SHIPPING DIMENSIONS 54 1/2 X 26 X 25 3/4 54 1/2 X 29 X 25 3/4
SHIPPING WEIGHT 157 183
MAXIMUM DESIGN OUTLET TEMP. 170 F
AUXILIARY LIMIT 130 F 140 F
UNIT SPECIFICATIONS HIGH AIR FLOW MODELS
