PARTS LIST
THERMOSTATICALLY-CONTROLLED ROYAL ENGLISH OAK MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 24 of this manual.
KEY PART NUMBER
NO. CLD3924NTB CLD3924PTB CLD3018NTA CLD3018PTA DESCRIPTION QTY.
1 117230-05 117230-05 117230-02 117230-02 Middle Log (#1) 1
2 117230-04 117230-04 117230-01 117230-01 Rear Log (#2) 1
3 117230-06 117230-06 117230-03 117230-03 Right Front Log (#3) 1
4 117230-07 117230-07 117230-07 117230-07 Left Front Log (#4) 1
5 117230-08 117230-08 117230-08 117230-08 Left Top Log (#5) 1
6 117230-10 117230-10 117230-10 117230-10 Right Top Log (#6) 1
7 117230-09 117230-09 117230-09 117230-09 Middle Top Log (#7) 1
8 102844-01 102844-01 102844-02 102844-02 Lower Bracket 1
9 098867-14 098867-10 098867-14 098867-10 Gas Regulator 1
10 102981-01 102981-01 102981-01 102981-01 Inlet Tube 1
11 102983-01 102983-01 111331-08 102983-06 Outlet Burner Tube 1
12 099056-16 099056-17 099056-18 099056-19 Burner Orifice Injector 1
13 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1
14 102772-01 102772-01 102980-01 102980-01 Burner 1
15 101329-20 101329-19 101329-21 101329-30 Thermostat Gas
Valve Assembly 1
16 102979-01 102979-01 102979-01 102979-01 Thermostat Bracket 1
17 098544-01 098544-01 098544-01 098544-01 Thermobulb Clip 1
18 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1
19 099387-09 099387-09 099387-09 099387-09 Pilot Tube 1
20 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
21 104285-01 104286-01 104285-01 104286-01 ODS Pilot 1
22 M11084-38 M11084-38 M11084-38 M11084-38 Hex Screw, #8-18 x .38 13
23 098249-01
098249-01 098249-01 098249-01 Nut, M5 2
24 099211-01 099211-01 099211-01 099211-01 Hex Screw, 10-16 x 2.50 2
25 ** ** ** ** Painted Base Assembly 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
101054-01 101054-01 101054-01 101054-01 Lighting Instructions
Plate 1
100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-02 100639-02 100639-02 100639-02 Caution Decal 1
101137-02 101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
** Not a field replaceable part.
