www.desatech.com 113101-01C 33
PARTS LIST
VARIABLE MANUALLY-CONTROLLED WINCHESTER OAK MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 24 of this manual.
PART NUMBER
KEY CGS2718N CGS2718P CGS3124N CGS3124P
NO. SGS3124N SGS3124P DESCRIPTION QTY.
1 113571-02 113571-02 113572-02 113572-02 Back Log (#1) 1
2 113571-01 113571-01 113572-01 113572-01 Front Log (#2) 1
3 113571-03 113571-03 113572-03 113572-03 Left Crossover Log (#3) 1
4 113571-04 113571-04 113572-04 113572-04 Right Crossover Log (#4) 1
5 ** ** ** ** Painted Base Assembly 1
6 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1
7 098276-01 098276-01 098276-01 098276-01 Hex Head Plug, 1/8" NPT 1
8 098867-14 098867-10 098867-14 098867-10 Gas Regulator 1
9 111331-04 102780-05 111331-04 102780-05 Outlet Burner Tube 1
10 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1
11 099056-20 099056-21 099056-18 099056-19 Burner Orifice Injector 1
12 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1
13 102963-02 102963-02 102773-03 102773-03 Burner 1
14 102568-07 102568-08 102568-07 102568-08 Control Valve 1
15 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1
16 098354-01 098354-01 098354-01 098354-01 Control Knob 1
17 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1
18 098249-01 098249-01 098249-01 098249-01 Nut, M5 2
19 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1
20 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
21 104285-01 104286-01 104285-01 104286-01 ODS Pilot 1
22 M11084-38 M11084-38 M11084-38 M11084-38 Screw, Hex Head
(#8-18 x .38) 8
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
101055-02 101055-02 101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 100639-01 Caution Decal 1
101449-04 101449-04 101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
** Not a field replaceable part.
