Thank you for purchasing a Demco Kar-Kaddy. We feel you have made a wise choice and hope you
are completely satisfied with your new piece of equipment.
GENERAL INFORMATION
1. Unless otherwise specified, high-strength (grade 5)
(3 radial-line head markings) hex head bolts are
used throughout assembly of this piece of equip-
ment.
2. Whenever the terms "LEFT" and "RIGHT" are
used in this manual it means from a position behind
the
Kar-Kaddy and facing forward.
3. When placing a parts order, refer to this manual for
proper part numbers and place order by PART NO.
and DESCRIPTION.
Introduction
To contact NHTSA, you may either call the
Auto Safety Hotline toll-free at
1-800-424-9393 (or 366-0129 in
Washington, D.C. area) or write to:
NHTSA,
U.S. Department of Transportation
Washington, D.C. 20590.
You can also obtain other information about
motor vehicle safety from the Hotline.
"Reporting Safety Defects"
If you believe that your vehicle has a defect
which could cause a crash or could cause injury or
death, you should immediately inform the National
Highway Traffic Safety Administration (NHTSA) in
addition to notifying Dethmers Manufacturing Com-
pany (DEMCO).
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA
cannot become involved in individual problems be-
tween you, your dealer, or Dethmers Manufacturing
Company (DEMCO).
TABLE OF CONTENTS
General Information .................................................................................................................................................... Page 2
Tow Dolly safety guide ........................................................................................................................................... Page 3-10
Bolt Torque ................................................................................................................................................................ Page 11
Tongue & Ramp Installation ..................................................................................................................................... Page 12
Fender Assembly Installation .................................................................................................................................... Page 13
Safety, Maintenance, & Important Loading Instructions .......................................................................................... Page 14
Loading Angle Clearance Guide ............................................................................................................................... Page 14
Loading Instructions ............................................................................................................................................. Page 15-17
Kar-Kaddy KK370SB Parts Breakdown and List ................................................................................................ Page 18-19
Winch Assembly ........................................................................................................................................................ Page 20
Latch Assembly ......................................................................................................................................................... Page 20
License Plate Bracket Assembly .............................................................................................................................. Page 21
Fender Assembly ...................................................................................................................................................... Page 21
Limited Warranty Information .................................................................................................................................... Page 22
DA91 Brake Actuator Parts Breakdown and List ..................................................................................................... Page 23
10" Self-Adjusting Brake Cluster Parts Breakdown and List ................................................................................... Page 24
Surge Brakes Parts Breakdown and List .................................................................................................................. Page 25
Testing Lights Before Use ......................................................................................................................................... Page 26
Wiring Diagram .......................................................................................................................................................... Page 26
Kar-Kaddy Toe-In Adjustment .................................................................................................................................. Page 27
Wheel Jack, Deflector, & Light Bar (optional) Parts Breakdown and List ............................................................... Page 28
Winch, Tool Box, & Spare Tire w/Mounting Bracket (optional) Parts Breakdown and List .................................... Page 31
