6
Jumper
Jumper Name Description
JBAT CMOS RAM Clear Function Setting 3-pin Block
JP1 KB/MS Power on Function Setting 3-pin Block
JP3/JP5 USB Power on Function Setting 3-pin Block
Connectors
Connector Name Description
DC12V_IN (for NC63P ) DC power Connector DC Jack
SATA_PWR(for NC63P) Power out Connector 4-pin Connector
ATXPWR(for NC63) ATX Power Connector 24-pin Connector
SATA1~SATA4 Serial ATAII Connector 7-pin Connector
KB from UK1 PS2 Keyboard Connector 6-pin Female
USB from UK1,UL1 USB Port Connectors 4-pin Connectors
LAN from UL1 RJ-45 LAN Connectors 8-pin Connectors
HDMI High Definition Multimedia
Interface 19-pin Connector
DVI Digital Visual Interface 29-pin Connector
VGA Video Graphic Attach Connector 15-pin Female
AUDIO AUDIO Connector 9-pin Connectors
Headers
Header Name Description
FP_AUDIO Front panel audio Headers 9-pin block
CDIN CD Audio-In Header 4-pin Block
USB1; USB2 USB Headers 9-pin Block
JW_FP
(PWR LED/ HD LED/
/Power Button /Reset) Front Panel Header
(PWR LED/ HD LED/ /Power Button
/Reset) 9-pin Block
PWR LED Power LED 3-pin Block
SPEAK Speaker Header 4-pin Block
COM1 Serial Port Header 9-pin Block
