Jetway Computer NC92 - Manual (Page 8)

K.B&USB Power on
Jumper (JP1)
Parallel Header
PS/2 Mouse Keyboard
Intel CPU
ATX Power
Connector DDRII
DIMM
COM/VGA
Connector
4
Front Panel
Connector
Clear CMOS (JBAT)
Intel 945GC Chipset
Speak Header.
PWR LED
Header
USB2.0 Header
(USB2, USB3)
ATA100
IDE Connector
SATA
Connector
8Mbit SPI Flash ROM BIOS
32-bit PCI Slot CD Audio In
USB 2.0 Port
Front Panel Audio
RJ45 LAN
Over USB Port
USB 2.0 Port
Audio Connector
Daughter Board
Expansion Connector
SYSFAN2
SYSFAN1
COM
Header
Realtek
RTL8111C LAN
ALC 662
Audio Codec
CPUFAN1
Intel 82801G
ICH Chipset
Floppy Disk
Drive Connector
USB Power on
Jumper (JP3)
