Step 8 Slide another mounting tab under the
bracket under the 2 lower mounting holes. The
tab thinner portion of the tab should go under
the lower rear lip of the speaker.
NOTE: In some installations, as was the case on
this Samsung TV, one of the brackets covered one
of the input terminals. So a speaker wire was
connected before the bracket was screwed in
place.
Step 9 Align the 2 lower holes in the bracket
with the holes in the mounting tab and install 2
screws.
Step 10 Repeat steps 5 to 8 with the second
bracket.
