Warning: Never touch the glass or white powder of the lamp as finger
oil, dust or water will damage the lamp.

5. Replace a new lamp.

Hold the new lamp by its base (we suggest you to put gloves on) and then push it
firmly into the usage position. Remember to push the bottom of the lamp back to its
position first and then the head. Tighten the screws.

3. Unscrew the two screws on the bottom of the lamp module.

Then release the head screw of the lamp module.

4. Take out the used lamp from the usage position. Take out the head of the lamp first

and then the bottom. Be careful of the hot lamp.

Lamp Base

Lamp

6. Close the metal cover and then tighten the screws.

Close the lamp door and then tighten the screw beside the lamp latch.

Bottom Screws

Head Screw

Bottom Lamp

Head Lamp
