PARTS LIST
CGD3018NT, CGD3924NT, CGD3930NT
PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 36 of this manual.
Thermostatically-Controlled Smoky Mountain
Oak Models
KEY
CGD3018NT
CGD3924NT
CGD3930NT
NO.
PART NUMBER
PART NUMBER
PART NUMBER
DESCRIPTION
QTY.
1
103008-02
110090-03
103008-03
Back Log (#1)
1
2
103009-02
110090-02
103009-03
Middle Log (#2)
1
3
103010-02
110090-01
103010-03
Front Log (#3)
1
4
103011-02
110090-04
103011-01
Crossover Log (#4)
1
5
102775-09CK
102775-05CK
102775-07CK
Painted Base Assembly
1
6
102844-02
102844-01
102844-01
Lower Bracket
1
7
102966-02
102966-01
102966-01
Upper Bracket
1
8
098867-14
098867-14
098867-14
Gas Regulator
1
9
102810-03
102810-03
102810-03
Inlet Tube
1
10
102983-03
102983-01
102983-01
Outlet Burner Tube
1
11
099056-26
099056-16
099056-16
Burner Orifice Injector
1
12
102843-01
102843-01
102843-01
Burner Clip
1
13
102980-01
102772-01
102772-01
Burner
1
14
101329-21
101329-20
101329-20
Thermostat Gas Valve Assembly
1
15
102979-02
102979-01
102979-01
Thermostat Bracket
1
16
098544-01
098544-01
098544-01
Thermobulb Clip
1
17
102445-01
102445-01
102445-01
Piezo Ignitor
1
18
099387-09
099387-09
099387-09
Pilot Tube
1
19
098271-10
098271-10
098271-10
Ignitor Cable
1
20
104285-01
104285-01
104285-01
ODS Pilot
1
21
M11084-38
M11084-38
M11084-38
Hex Screw, #8-18 x .38
15
22
098249-01
098249-01
098249-01
Nut, M5
2
23
099211-01
099211-01
099211-01
Hex Screw, 10-16 x 2.50
2
PARTS AVAILABLE — NOT SHOWN
100563-01
100563-01
100563-01
Warning Plate
1
101054-01
101054-01
101054-01
Lighting Instructions Plate
1
100565-01
100565-01
100565-01
Warning Plate Fastener
1
100639-01
100639-01
100639-01
Caution Decal
1
101137-02
101137-02
101137-02
Hardware Kit
1
GA6060
GA6060
GA6060
Lava Rock
1
