PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 36 of this manual.
Variable Manually-Controlled
PART NUMBER
KEY CCL3018N CCL3924N
NO. CGD3018N CGD3924N CGD3930N DESCRIPTION QTY.
1 103008-02 103008-01 103008-03 Back Log (#1) 1
1a 105925-04 105925-03 ____ Back Log (#1) 1
2 103009-02 103009-01 103009-03 Middle Log (#2) 1
2a 105924-04 105924-03 ____ Middle Log (#2) 1
3 103010-02 103010-01 103010-03 Front Log (#3) 1
3a 105923-04 105923-03 ____ Front Log (#3) 1
4 103011-02 103011-01 103011-01 Crossover Log (#4) 1
4a 105926-04 105926-03 ____ Left Back Crossover Log (#4) 1
5 105927-04 105927-03 ____ Left Top Crossover Log (#5) 1
6 105928-04 105928-04 ____ Right Bottom Crossover Log (#6) 1
7 102966-02 102966-01 102966-01 Upper Bracket 1
8 098867-14 098867-14 098867-14 Gas Regulator 1
9 102798-01 102798-01 102798-01 Inlet Tube 1
10 102779-03 102779-01 102779-01 Outlet Burner Tube 1
11 099056-26 099056-16 099056-16 Burner Orifice Injector 1
12 102843-01 102843-01 102843-01 Burner Clip 1
13 102980-01 102772-01 102772-01 Burner 1
14 102568-07 102568-05 102568-05 Control Valve 1
15 098508-01 098508-01 098508-01 Valve Retainer Nut 1
16 098354-01 098354-01 098354-01 Control Knob 1
17 102445-01 102445-01 102445-01 Piezo Ignitor 1
18 099387-08 099387-08 099387-08 Pilot Tube 1
19 098271-10 098271-10 098271-10 Ignitor Cable 1
20 104285-01 104285-01 104285-01 ODS Pilot 1
21 M11084-38 M11084-38 M11084-38 Hex Screw, #8-18 x .38 11
22 098276-01 098276-01 098276-01 Hex Head Plug, 1/8 NPT 1
23 098249-01 098249-01 098249-01 Nut, M5 2
24 102775-04CK 102775-01CK 102775-03CK Painted Base Assembly 1
25 102844-02 102844-01 102844-01 Lower Bracket 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 Warning Plate 1
101055-02 101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 Caution Decal 1
101449-04 101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 Lava Rock 1
PARTS LIST
CGD3018N, CGD3924N, CGD3930N, CCL3018N, CCL3924N
