19 104402
OWNER’S MANUAL
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 17 of this manual.
KEY PART NUMBER FOR
NO. VN2000BTD VN2800BTD DESCRIPTION QTY.
1 098304-01 098304-01 Screw, #10 x 3/8" 2
2 098742-13 098742-14 Front Panel 1
3 103476-01 103476-02 Grill Guard 1
4 101108-01 101108-01 Removable Speed Clip 2
5 104189-01 104189-02 Bottom Glass Retainer 1
6 098260-09 098260-10 Glass Panel 1
7 NJF-8C NJF-8C Hex Nut 1
8 M11084-26 M11084-26 Screw, #10 x 3/8" 6
9 104618-01BR 104618-02BR Deflector Unit 1
10 098271-03 098271-03 Ignitor Cable 1
11 098249-01 098249-01 Nut, M5 2
12 103594-05 103594-05 ODS/Pilot Assembly 1
12-1 098514-01 098514-01 Thermocouple 1
12-2 106842-01 106842-01 Ignitor Electrode 1
13 103446-01 103447-01 Burner 1
14 099387-03 099387-03 3/16" Pilot Tubing 1
15 103845-06 103845-08 Injector 1
16 099066-01 099066-01 Mounting Bracket 1
17 099415-07 099415-11 Pressure Regulator 1
18 099553-01 099553-01 Pilot Shield 1
19 103255-01 103255-01 3/8" Outlet (Burner) Tubing 1
20 103256-01 103256-01 3/8" Inlet Tubing 1
21 098522-10 098522-12 Thermostat Gas Valve 1
22 104617-03 104617-04 Cabinet, Woodgrain 1
23 097159-04 097159-04 Piezo Ignitor 1
24 M11084-38 M11084-38 Screw, #8 x 3/8" 2
PARTS AVAILABLE — NOT SHOWN
098305-01 098305-01 Control Position Label 1
100642-01 100642-01 Hardware Assembly 1
