Maintenance
64 7
Inside light
1. Open the trunk.
2. Loosen the retaining screw of the trunk
lid cover and then remove the cover.
3. Disconnect the connector and then
remove the nuts by turning the nuts
counter clockwise.
4. Take the light assembly out.
5. Remove the socket from the assembly
by turning the socket counterclockwise
until the tabs on the socket align with
the slots on the assembly.
6. Remove the bulb by pulling it out
7. Insert a new bulb by inserting it into the
socket.
8. Install the light assembly to the trunk.
9. Reinstall the nuts and connector and
then the trunk lid cover by pushing in
the screw.
OMD070039
OMD070040
OMD070037
OMD070038C
