Features of your vehicle
126 4
■ Making a Phone Call
• Direct Calling
➀
Press button.
➁
Say the following command.
- Call : Connects the call to John.
- Call on : Connects
the call to John’s mobile phone number.
- Call at : Connects
the call to john’s home number.
- Call in : Connects
the call to John’s office number.
Note:
Calls can be immediately connected
to contacts who name or voice tag are
saved in the phonebook(or contacts).
• Calling by Name
A phone call can be made by speaking
names registered in the audio system.
➀
Press button.
➁
Say “Call”.
➂
Say “By name” when prompted.
➃
Say desired name (in Phonebook or
voice tag).
➄
Say desired location (phone number
type). Only stored locations can be
selected.
➅
Say “Yes” to confirm and make a call.
✽ ✽ Tip
A shortcut to each of the following func-
tions is available:
1. Say “Call Name”
• Dialing by Number
A phone call can be made by dialing the
spoken numbers. The system can recog-
nize single digits from zero to nine.
➀
Press button.
➁
Say “Call”.
➂
Say “By number” when prompted.
➃
Say desired phone numbers.
➄
Say “Dial” to complete the number and
make a call.
✽ ✽ Tip
A shortcut to each of the following func-
tions is available:
➀
Say “Dial Number”
➁
Say “Dial ”
✽ ✽ Tip
■ Voice Operation
To get the best performance out of the
Voice Recognition System, observe the
followings:
- Keep the interior of the vehicle as
quiet as possible. Close the window
to eliminate surrounding noise
(traffic noise, vibration sounds,
etc), which may disturb recogniz-
ing the voice command correctly.
- Speak a command after a beep
sound within 5 seconds. Otherwise
the command will not be received
properly.
- Speak in a natural voice without
pausing between words.
- While receiving voice commands,
press the button on the steer-
ing wheel remote controller to ter-
minate guidance. Voice command
will convert back to waiting mode
to allow the user to say a new voice
command.
