Page 2-2
INSTALLATION
HT2000/MAX200 Water Muffler Instruction Manual
UPON RECEIPT
1. Remove the Water Muffler system and save the carton. The carton is reusable and
provides an impact-resistant box for transporting or storing the system and parts. The
carton should include either of the following systems:
HT2000/MAX200 Water Muffler System with Hoses
020423 Cap, HT2000/MAX200 shield
024022 Hose assembly, #12 x 50 ft. with:
015262 Swivel, #12 3/4 Syn hose Brs (attached to hose)(2)
015262 Ferrule, 1.150 ID x .88 Brs (attached to hose)(2)
046020 Hose:3/4" ID Blk
024023 Hose assembly, #12 x 4 ft. with:
015262 Swivel, #12 3/4 Syn hose Brs (attached to hose)(2)
015262 Ferrule, 1.150 ID x .88 Brs (attached to hose)(2)
015052 Adapter, 3/4 NPT x #12 (attached to hose)
027009 Filter, 2" NPT, water
015578 Reducer bushing, 2" x 3/4", galv
015509 Nipple 2" x CL, galv
046020 Hose:3/4" ID Blk
027012 Silicone lubricant
028042 Water supply, W-M, 240/480V, 3PH, 60 Hz (refer to page 4-6)
or
028299 Water supply, W-M, 380-415V, 3PH, 60 Hz (refer to page 4-6)
or
028308 Water supply, W-M, 600V, 3PH, 60 Hz (refer to page 4-6)
034148 Nozzle assembly, W-M, HT2000/MAX200 (refer to page 4-5)
020566 Shield, HT2000/MAX200 W-M
020618 Shield, HT2000/MAX200 W-M - 100 Amp
HT2000/MAX200 Water Muffler System without Hoses
020423 Cap, HT2000/MAX200 shield
015053 Swivel, #12 (3)
015052 Adapter, 3/4 NPT x #12
027009 Filter, 2" NPT, water
015578 Reducer bushing, 2" x 3/4", galv
015509 Nipple 2" x CL, galv
027012 Silicone lubricant
028042 Water supply, W-M, 240/480V, 3PH, 60 Hz (refer to page 4-6)
or
028299 Water supply, W-M, 380-415V, 3PH, 60 Hz (refer to page 4-6)
or
028308 Water supply, W-M, 600V, 3PH, 60 Hz (refer to page 4-6)
034148 Nozzle assembly, W-M, HT2000/MAX200 (refer to page 4-5)
020566 Shield, HT2000/MAX200 W-M
020618 Shield, HT2000/MAX200 W-M - 100 Amp
5-95
