Dual XDMA6700 - Manual (Page 5)

Faceplate Removal
Semi-Permanent
Faceplate Installation
Power On/Off
Mode
Volume
Programmable
Turn-On Volume
Mute
Preset EQ Curves
General Operation
XDMA6700 OPERATION
5
Press RELEASE and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
Remove trim ring, and install supplied #1 x 7/3” Phillips
head screw through left side of mounting frame into faceplate.
Press POWER or any other button (except eject) to turn the
unit on. Inserting a disc will turn the unit on automatically.
Press POWER to turn the unit off.
Press MODE to select between AM/FM, CD player, auxiliary
input, iPod (optional), and Bluetooth (optional). Modes of
operation are indicated in the display.
NOTE: CD, iPod, and Bluetooth modes will not appear
unless a CD is inserted, IPCM (iPod cable - sold separately)
and iPod are attached, or BTM60 (Bluetooth module - sold
separately) is attached.
Adjust volume using rotary encoder (00-6).
Press and hold POWER for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
