PARTS LIST
Firebox
This list contains replaceable parts used in your firebox. When ordering parts,
follow the instructions listed under Replacement Parts on page 19 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 101872-03 Firebox Top 1
2 101889-01 Firebrick Retainer 3
3 101929-01 Rear Firebrick 1
4 101932-01 Side Firebrick 2
5 103207-01 Outer Casing 1
6 103208-01 Outer Shell Base 1
7 103245-01 Firebox Wrapper 1
8 103297-01 Assembly Screen 2
9 103772-01BR Hood 1
10 103774-01BR Front Assembly 1
11 103787-01BR Firebox Bottom 1
12 103809-01 Screen Rod 2
13 103770-01 Velcro Strips 2
14 101348-01 Firebox Support 2
15 101357-01 Outer Casing Top 1
16 M11084-26 Hex Head Screw, #10-16 49
17 103771-01 Strain Relief Fitting 1
18 098304-01 Phillips Pan Head Screw, #10 13
19 099230-01 Hex Head Screw 3
20 099230-02 Shoulder Screw 2
21 101629-01 Bushing 2
22 103769-01 Duplex Outlet 1
23 M12461-02 Screw, Outlet Mounting 1
PARTS AVAILABLE — NOT SHOWN
097809-02 Male Fitting 1
101628-02 Flexible Connector 1
Model FB32C
