2406 Assembly
Page - 24
H A R D W A R E L I S T I N G
A S S E M B LY
C A T A L O G
Key #
Qty.
Part Number
Description
A
8
11-BTN-12112WZ
1/2"-13 x 1 1/2" Button Head Screw
B
2
11-BTN-5162WZ
5/16"-18 x 2" Button Head Screw
D
2
11-FLA-3812WZ
3/8"-16 x 1/2" Flat Head Cap Screw
E
6
11-FLA-3834WZ
3/8"-16 x 3/4" Flat Head Cap Screw
F
1
11-BTN-381WZ
3/8"-16 x 1" Button Head Screw
G
2
11-FLA-121WZ
1/2"-13 x 1" Flat Head Cap Screw
H
1
11-BTN-381
3/8"-16 x 1" Button Head Screw
J
3
11-BTN-38234WZ
3/8"-16 x 2 3/4" Button Head Screw
K
2
11-BTN-5161
5/16"-18 x 1" Button Head Screw
L
4
11-BTN-5163WZ
5/16"-18 x 3" Button Head Screw
M
6
11-BTN-3834WZ
3/8"-16 x 3/4" Button Head Screw
N
6
11-SKT-14114
1/4"-20 x 1 1/4" Socket Head Screw
Q
3
11-FLA-141WZ
1/4"-20 x 1" Flat Head Cap Screw
R
2
11-SKT-141
1/4"-20 x 1" Socket Head Screw
S
7
11-BTN-516114WZ
5/16" x 1 1/4 Button Head Screw
T
16
11-SET10(32)18
10/32 x 1/8 Set Screw
U
1
11-HEX-516412WZ
5/16" x 4 1/2" Hex Head Screw
V
4
11-FLA-381WZ
3/8" x 1" Flat Head Screw
AA
8
13-LOK-121INT
1/2" Lock Washer
AB
8
13-FLT-12SAEWZ
1/2" Flat Washer
AC
2
13-FLT-14SAEWZ
1/4" Flat Washer
AD
6
13-FLT-14INTB
1/4" Flat Washer
AE
10
13-FLT-38SAEWZ
3/8" Flat Washer
AF
7
13-LOK-38INT
3/8" Lock Washer
AG
2
13-FLT-516SAE
5/16" Flat Washer
AH
2
13-LOK-516INTB
5/16" Lock Washer
AJ
2
13-LOK-38WZ
3/8" Split Washer
AK
1
13-FLT-38SAEB
3/8" Flat Washer
AL
1
13-LOK-38INTB
3/8" Lock Washer
AM
12
13-FLT-516SAEWZ
5/16" Flat Washer
AN
4
13-LOK-516INT
5/16" Lock Washer
BA
9
12-LOK-14WZ
1/4" Lock Nut
BC
1
12-FLG-12(13)SB
Serrated Hex Nut
BD
2
12-LOK-516WZ
5/16" Lock Nut
CA
2
19-PAD-1
Bumper Stopper
CB
1
20-GSP-Y2063
Gas Spring
CC
6
14-BRG-34138
Bearing
CD
1
30-RPN-7163
Top Weight Roll Pin
CE
1
14-BRG-PAC4962
Guide Bearing (tall)
CF
1
14-BRG-PAC4982
Guide Bearing (short)
CG
8
1/2-13UNC
Insert
CH
2
20-LNK-CONN43
Master Chain Link
CJ
4
14-RNG-ERETRG (3/4)
Retaining Ring
CK
1
20-GLD-38112
Adjustable Stop
CL
1
10-LRD-12
Selector Pin Lanyard
CM
3
18-PUL-325/W38T
3 1/4" Pulley
CN
1
18-PUL-325/W38
3 1/4" Pulley
CP
4
3/8-13UNC
Insert
CQ
2
14-OIL-34F
3/4" Oilite
CR
1
26-STD-PLAS133
Delrin Stop (Long)
CS
4
26-STD-PLAS127
4 3/4" LG Knurled Sleeves
