A S S E M B LY
C A T A L O G
2406 Assembly
Page 23
FITNESS SYSTEMS
R
HOIST
P A R T L I S T I N G
Key #
Qty.
Part Number
Description
1
1
26-STD-SX667
Seated Assembly
2
1
26-STD-SX669
Weight Cage
3
4
26-STD-PLAS195
Rubber Foot Pad
4
2
26-STD-PLAS187RV
2" x 4" End Caps (VH)
5
2
26-STD-SM386
Shaft
6
1
26-STD-SM382
Shaft
7
1
26-STD-PLAS187RH
2" x 4" End Cap (HH)
8
1
26-STD-SX668
Back Adjuster Assembly
9
1
26-STD-SM339
Shaft
10
1
26-STD-SX673
Back Adjuster Assembly
11
1
26-STD-SM129
Pull Pin (long)
12
1
26-STD-SW112
Stem (11)
13
2
16-CAP-22
2" x 2" End Cap
14
6
26-STD-PLAS183
End Cap Plug
15
1
26-STD-SX670
Left Inner Thigh Assembly
16
1
26-STD-SX671
Right Inner Thigh Assembly
17
2
26-STD-SM385
Arm Axle
18
1
26-STD-SM128
Pull Pin (short)
19
1
26-STD-PLAS193
Cam Stopper
20
1
26-STD-SX672
Adjustable Handle Assembly
21
1
26-STD-SX509
ROM/CAM Assembly
22
1
26-STD-SX155
Center RH (BRK) Assembly
23
2
26-STD-SM295
Add On Rods
24
3
26-STD-SWADD7
Add On Weights
25
1
26-STD-SM134
Weight Selector Pin
26
1
26-STD-SWTOP13
20lbs. Steel Weight Plate
27
10
26-STD-SW104
20lbs. Intermediate Wieght Plates
28
2
26-STD-PLAS201
Weight Bumpers
29
2
26-STD-PLAS134
Guide Rod Bushings
30
1
26-STD-SA193
Stainless Steel Adjustable Plate
31
2
26-STD-SG136
Guide Rods
32
1
26-STD-SU107818
Upholstery Assembly
33
1
26-STD-SU131214
Upholstery Assembly
34
1
26-STD-SU991332L
Left Knee Upholstery
35
1
26-STD-SUB991332L
Left Knee Backing
36
1
26-STD-SUB991332R
Right Knee Upholstery
37
1
26-STD-SU991332R
Right Knee Backing
38
1
26-STD-PLAS206-9
Rubber Grips (5 1/2" LG.)
39
1
26-STD-SSH174
Standard Shield
40
2
26-STD-SM199
Quick Release Cable Lock
41
2
26-STD-SC192
Arm Cable
42
2
26-STD-SM323
Aluminum End Cap
43
4
26-STD-SM324
Aluminum Ring
44
2
26-STD-SM209
Pull Pin to Chain Link Connection
45
1
26-STD-SA195
Stainless Steel Adjustable Plate
46
6
26-STD-SP467
Belt Clamp
47
1
26-STD-SX674
Pulley Bracket
48
1
15-BLT-1516
Cam Belt 37" x 15/16" x 1/8"
49
1
26-STD-SP592
Foot Plate
50
1
26-STD-SP599
U-Bracket
51
1
15-BLT-1516
Cam Belt 90" x 15/16" x 1/8"
52
2
26-STD-PLAS206-4
Rubber Grips (11 9/16" LG.)
53
1
26-STD-PLAS206-7
Rubber Grip (4" LG.)
54
1
26-STD-SM294
Belt Retainer Shaft
55
1
26-STD-SM293
1 5/8" x 2 1/16" LG. Tube
56
1
20-NON-418B
4" x 18 Rubberized Non-Skid
57
2
26-STD-SM323R
Aluminum End Cap (Red)
