ITEM NO. PART NUMBER DESCRIPTION QTY.
36 021-0003415 DECAL PULL UP 1
37 021-0003820 DECAL PIVOT POINT (ROUND) 1
38 021-0003421 DECAL ROM 1-7 1
39 021-0003427 DECAL ADJUST 1
40 021-0003422 DECAL WEIGHT STACK (1-12) 1
41 021-0003543 DECAL MOVING PARTS 1.20" X 2.38" (VERTICAL) 2
43 026-01M0128-1 PULL PIN CAP 1
44 026-01M0128-3 PULL-PIN PLUNGER 1
45 026-01M0199 QUICK RELEASE CABLE LOCK Ø 1/4" 1
46 026-01M0209 PULL-PIN TO CHAIN LINK 1
47 026-01M0238 FLATHEAD CAP Ø2.00" ALUM. 1
48 026-01M2360 SHAFT - 25mm X 4.71" LG. 1
49 026-01M2629 SHAFT - 1.181" X 4.71" LG. 2
50 026-01M0932 ALUMINIUM CAP: Ø1.25" ID 2
51 026-01M0933 ALUMINUM RING: Ø1.25" ID 2
52 026-01M0936 ALUMINIUM RING: 1.00" I.D. 1
53 026-01X3773 25MM SHAFT ASSEMBLY 2
54 026-01M0971 HEAVY FLANGED SPACER: Ø.6690" O.D. X Ø.34" I.D. X 1.56" LG. 2
60 026-01M2381 SHAFT .984" X 2.9400 LG. 2
61 026-01P2653 'H' PLATE 1
62 026-01P4162 LEG ROM PLATE 1
63 026-01P2719 CABLE SHIELD 1
64 026-01P4163 ROM PLATE 1
65 026-01F0267 FLANGE 1
66 026-01PL0206-14 GRIP 1.00" X 6.25" LG. 1
67 026-01PL0235-10 GRIP OPEN END 1.19" X 10.00" LG. 2
68 026-01PL2122 OVAL-SHAPED RUBBER FOOT 4
69 026-01PL2154 PLASTIC KNOB: BASE 1.00" ID 1
70 026-01PL2155 PLASTIC KNOB: CAP 1.00" ID 1
71 026-01M0934 ALUMINUM CAP: 1.50" ID 1
73 013-0302008 5/16" SAE FLAT WASHER (WZ) 14
74 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 23
75 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 32
PART LIST CONTINUED
RS-1402-A ASSEMBLY
OWNER'S MANUAL
PAGE 28
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
