PART LIST
RS-1402-A ASSEMBLY
OWNER'S MANUAL
PAGE 27
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
026-01X2513
ARM ADJUSTER ASSEMBLY
1
2
026-01X3806
MAIN FRAME ASSEMBLY
1
3
026-01X2487
CROSS MEMBER ASSEMBLY
1
4
026-01X3805
BASE ASSEMBLY
1
5
026-01X2490
REAR LINK ASSEMBLY
1
6
026-01X3807
FRONT PIVOT ASSEMBLY
1
7
026-01X2498
BACK SUPPORT ASSEMBLY
1
8
026-01X2500
BACK SUPPORT FRONT LINKAGE
1
9
026-01X2508
BACK SUPPORT REAR LINKAGE
1
10
026-01X3770
FRONT LINK ASSSEMBLY
1
11
026-01X2622
CROSS BAR ASSEMBLY
1
12
026-01X3772
CAM ASSEMBLY
1
13
026-01X3792
SHIN PAD MOUNT
1
14
022-01PDR001A
ROLLER PAD ASSEMBLY
2
15
026-01X3809
ROLLER BAR ASSEMBLY
1
16
022-01PD2049-A
SEAT PAD ASSEMBLY
1
17
022-01PD2055
UPHOLSTERED HEAD PAD
1
18
022-01PD2085-A
BACK PAD ASSEMBLY
1
19
026-01X5630
CHAIN LINK REPLACEMENT
1
20
010-01C0412
CABLE ASSEMBLY RS-1402-A - 156 3/4" LG.
1
21
011-0411001
SET SCREW: 1/4"-28 X .25" LG. (SS)
6
22
026-01M2647
END CAP: DOMED Ø 2.75" O.D.
1
23
014-0012013
BEARING: BALL BEARING Ø2.44" O.D. X Ø1.18" I.D.
4
24
026-01X0185
PULL-PIN ASSEMBLY
1
25
014-0014002
3/8-16 FLUSH MOUNT INSERT
2
27
014-0012014
BEARING: FLANGELESS - 25mm I.D.
12
28
014-0101002
BUSHING: OILITE FLANGED Ø.75 O.D X Ø.50 I.D X .38 LG.
10
29
014-0101005
BUSHING: OILITE FLANGED Ø1.38" O.D. X Ø1.00" I.D. X .81" LG.
2
30
018-0001003
CABLE PULLEY: Ø4.50"
3
31
019-0001001
PLUG BUMPER
5
32
020-0011009
SPRING
1
33
020-0006003
GAS SHOCK
1
34
021-0003113
DECAL PINCH POINT 1.63" X 3.25" (VERTICAL)
1
