Hoist Fitness RS-1401 - Manual (Page 23)

PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 22 RS-1401 ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY
41 026-01M0199 QUICK RELEASE CABLE LOCK Ø 1/4" 1
42 026-01M0209 PULL-PIN TO CHAIN LINK 1
43 026-01M0238 FLATHEAD CAP 2.00" ALUM. 1
44 026-01M0660 SHAFT: 1.00" O.D. X Ø .52" I.D. X 4.69" LG. 1
45 026-01M0920 SHAFT: 1.38" O.D. X Ø.52" I.D. X 4.69" LG. 2
46 026-01M0932 END CAP: ALUMINIUM 1.25" ID 2
47 026-01M0933 ALUMINUM RING: 1.25" ID 2
48 026-01M0936 ALUMINIUM RING: 1.00" I.D. 1
49 026-01X3147 1.00 SHAFT ASSEMBLY 2
50 026-01M0971 HEAVY FLANGED SPACER: Ø.67" O.D. X Ø.34" I.D. X 1.56" LG. 2
51 026-01M1043 FLATHEAD CAP 2.00" ALUM. (WITH RECESS) 1
52 026-01M1087 SHAFT 1.00" X 2.78" LG. 3
53 026-01P2619 ROM PLATE 1
54 026-01P2653 'H' PLATE 1
55 026-01P2719 CABLE SHIELD 1
57 026-01PL0206-14 GRIP 1.00" X 6.25" LG. 1
58 026-01PL0235-10 GRIP OPEN END 1.19" X 10.00" LG. 2
59 026-01PL2122 OVAL-SHAPED RUBBER FOOT 4
60 026-01PL2140 BLACK NYLON THREADED CAP 1
61 026-01PL2154 PLASTIC KNOB: BASE 1.00" ID 1
62 026-01PL2155 PLASTIC KNOB: CAP 1.00" ID 1
63 011-0107028 5/16"-18UNC X 4.00" HHB (WZ) 1
64 014-0019004-3 SCREW FOR 1.00 DIA SPLIT COLLAR (WZ) 4
65 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 5
66 011-0101034 3/8"-16UNC X 1.25" BHCS (WZ) 3
67 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 10
68 011-0002044 3/8"-16UNC X 1.00" FHCS (WZ) W/NYLON PATCH 1
69 011-0407027 3/8"-16UNC X 1.75" HHB (WZ) 3
70 011-0107009 3/8"-16UNC X 2.50" HHB (WZ) 1
71 011-0101047 1/2"-13UNC X 1.50" BHCS (WZ) 2
72 011-0102048 1/2"-13UNC X 6.00" FHS (WZ) 1
73 011-0107036 1/2"-13UNC X 5.75" HHB (WZ) 2
74 011-0107038 1/2"-13UNC X 4.25" HHB (WZ) 1
75 011-0107050 1/2"-13UNC X 3.75" HHB (WZ) 2
76 011-0407016 1/2"-13UNC X 3.00" HHB (WZ) 3
77 011-0107034 1/2"-13UNC X 3.25" HHB (WZ) 4
78 011-0407022 3/8"-16UNC X 1.00" HHB (WZ) 2
79 013-0302008 5/16" SAE FLAT WASHER (WZ) 14
80 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 22
81 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 37
