Important, Frame assembly, Owner's manual – Hoist Fitness RPL-5501 User Manual
Page 30
71
71
61
58
2
58
61
17
- WRENCH TIGHTEN HARDWARE.
HAND TIGHTENED HARDWARE.
- WRENCH TIGHTEN ALL PREVIOUSLY
FRAME ASSEMBLY
NOTE:
OWNER'S MANUAL
PAGE 27
RPL-5501 ASSEMBLY
AND RETIGHTEN BOLTS.
IT WILL BE NECESSARY TO LOOSEN SOME FRAME HARDWARE TO RE-ALIGN THE FRAME
ASSURE THAT YOUR UNIT IS ASSEMBLED SQUARE AND PERPENDICULAR. IF NOT,
*IMPORTANT*
NOW THAT THE RPL-5501 IS COMPLETELY ASSEMBLED TAKE TIME TO
