Page 14
PAGE 13
HF4664 ASSEMBLY
OWNER'S
MANUAL
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
026-01X2752
FRONT UPRIGHT ASSEMBLY
1
2
026-01X2499
BASE FRAME WELDMENT
1
3
026-01X2460
ADJUSTMENT TUBE ASSEMBLY
1
4
026-01X2476
GUIDE TUBE WELDMENT
1
5
026-01X2161
THREADED PULL-PIN ASSEMBLY
2
6
026-01X2507
MAIN FRAME WELDMENT
1
7
026-01X2525
HANDLE ASSEMBLY
1
8
026-01X2524
FRONT SUPPORT WELDMENT
1
9
026-01X2666
16.81" LG. ROLLER BAR ASSEMBLY
1
10
026-01X2661
FOOT REST WELDMENT
1
11
014-0101002
OILITE FLANGED, .75" O.D X .50" I.D X .38" LG.
2
12
014-0101017
BUSHING: OILITE FLANGED 1.00" ID X 1.38" OD X .75" LG.
4
13
016-0001003
1.50" X 2.50" END CAP (BLACK)
1
14
016-0201015
END CAP-F 2.00" X 3.00" (BLACK)
1
15
016-0201041
3.00" END CAP .06" WALL (BLACK)
2
16
016-0201038
1.25" ENDCAP (DOMED)
2
17
019-0002036
CLOSED END GRIP
1.25"
2
18
020-0014031
WHEEL
2 3/16"
2
19
022-01PD2046-A
UPHOLSTERY PAD
2
20
022-01PDR008
ROLLER PAD
4.00" X 7.00" LG.
2
21
026-01M1020
SHAFT, 1.00" O.D. X .531" I.D. X 3.219" LG.
1
22
026-01M1022
SHAFT, 1.00" O.D. X .531" I.D. X 2.812" LG.
1
23
026-01PL0125
E-Z GLIDE PLASTIC SLEEVE
4
24
026-01PL0151
PLASTIC WASHER
2.50"
4
25
026-01PL2005
PLUG BUMPER (2 STEM)
1
26
026-01T2720
ADJUSTMENT TUBE
1
27
011-0107011
5/16"-18UNC X 1.25" HHB (WZ)
4
28
011-0101026
3/8"-16UNC X 1.00" BHCS (WZ)
2
29
011-0407020
3/8"-16UNC X 1.75" HHB (WZ)
2
30
011-0107026
3/8"-16UNC X 2.25" HHB (WZ)
3
31
011-0407024
1/2"-13UNC X 2.75" HHB (WZ)
6
32
011-0407000
1/2"-13UNC X 3.50" HHB (WZ)
1
33
011-0107050
1/2"-13UNC X 3.75" HHB (WZ)
1
34
011-0101070
1/2"-13UNC X 4.00" HHB (WZ)
1
35
013-0102004
5/16" X 22mm USS FLAT WASHER (WZ)
4
36
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
10
37
013-0303007
3/8" FENDER WASHER (WZ)
2
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
