Dyna-Glo RMC-KFA120TDLX - Manual (Page 12)

22
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
17. PARTS LIST (WHEELS AND HANDLE)
1) RMC-KFA65TDLX MODEL
2) RMC-KFA120T/170TDLX MODELS
1 Handle 3231-0125-00 1
2 Cord Wrap 3231-0056-00 1
3 Hardware Kit HW-KFA1001 1
KEY NO. DESCRIPTION
PART NO.
RMC-KFA120TDLX RMC-KFA170TDLX
QTY
1 Handle Front 3551-0039-00 3551-0040-00 1
2 Handle 3231-0126-00 3231-0126-00 1
3 Cord Wrap 3221-0057-00 3221-0057-00 1
4 Wheel Axle 3541-0064-00 3541-0064-00 1
5 Wheel 2156-0026-00 2156-0026-00 2
6 Wheel Cap 3231-0100-00 3231-0100-00 2
7 Hardware Kit HW-KFA1008 HW-KFA1008 1
7-1 Screw(A) - - 4
7-2 Screw(B) - - 4
7-3 Flat Washer - - 2
7-4 Cotter Pin - - 2
7-5 Bushing - - 2
KEY
NO.
DESCRIPTION QTY
PART NO.
RMC-KFA65TDLX
21
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Rotor Kit
Blade
End Pump Cover
Nipple(Air)
Flange Bolt
Lint Filter
Output Filter
Filter Kit
End Filter Cover
Ball
Spring
Plug/Pump Adj.Kit
Flange Screw
Fan Assembly
Set Screw
Pressure Gauge
Fan Guard
Ignitor
Screw-PH2
Shell Upper Front
Shell Upper Rear
Shell Cover
Main P.C.B Assembly
Fuse
Thermostat Control Knob
Side Cover(R)
BRACKET SIDE COVER
RATING PLATE
Power Switch
Side Cover(L) SP-KFA1000
See SP-KFA1000
3531-0008-00
3541-0020-00
4329-0014-00
See SP-KFA1005
See SP-KFA1005
SP-KFA1005
3221-0029-00
See SP-KFA1006
See SP-KFA1006
SP-KFA1006
4319-0015-00
2154-0004-00
4323-0004-00
3740-0049-01
3221-0051-00
39E0-0025-00
4311-0024-00
3111-0220-00
3111-0223-00
3211-0020-00
215A-0023-00
SP-KFA1018
3231-0111-01
3211-0022-00
3131-0348-00
3221-0059-01
39A0-0044-00
3211-0024-00
SP-KFA1000
See SP-KFA1000
3531-0008-00
3541-0020-00
4329-0014-00
See SP-KFA1005
See SP-KFA1005
SP-KFA1005
3221-0029-00
See SP-KFA1006
See SP-KFA1006
SP-KFA1006
4319-0015-00
2154-0007-00
4323-0004-00
3740-0049-01
3221-0051-00
39E0-0025-00
4311-0024-00
3111-0221-00
3111-0224-00
3211-0020-00
215A-0023-00
SP-KFA1018
3231-0111-01
3211-0022-00
3131-0348-00
3221-0059-00
39A0-0044-00
3211-0024-00
23-8
23-9
23-10
23-11
23-12
23-13
23-14
23-15
23-16
23-17
23-18
23-19
23-20
24
25
26
27
28
29
30
31
32
33
33-1
33-2
34
35
36
37
38
KEY NO. DESCRIPTION
RMC-KFA120TDLX RMC-KFA170TDLX
PART NO.
ACCESSORIES
Air Pressure Gauge SP-KFA1011 (all models)
Thermostat SP-KFA1010 (all models)
FOR TECHNICAL ASSISTANCE SEE YOUR LOCAL RETAILER OR
CONTACT US AT:
Phone : 1-800-668-5323
