ACCESSORIES
Air Pressure Gauge SP-KFA1011 (all models)
Thermostat SP-KFA1010 (all models)
FOR TECHNICAL ASSISTANCE SEE YOUR LOCAL RETAILER OR
CONTACT US AT:
Phone : 1-800-668-5323
18
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
14. PARTS LIST(RMC-KFA65TDLX Model Only)
KEY NO. D E S C R I P T I O N P A R TN O . KEY NO. D E S C R I P T I O N P A R TN O .
Fuel Tank Assembly
Fuel Gauge
Fuel Gauge Cap
Fuel Cap Filter
Fuel Cap
Fuel Filter Assembly
Shell Lower Assembly
Bushing Grommet(S)
Bushing Grommet(L)
Twist Lock Stand Off
Nut Clip
Cord Bushing
Power Cord
Air Line
Temperature Limit Control
Flange Screw
Combustion Chamber
Photocell Bracket
Screw-BH
Photocell Assembly
Burner Head Assembly
Burner Head
Nipple(Air)
Nipple(Fuel)
Nozzle
Nozzle Seal Washer
Nozzle Seal Spring
Nozzle Sleeve
Spark Plug
Fiber Washer
Spring Washer
Flange Bolt
Fuel Line
Motor and Pump Assembly
Motor 3211-0018-00
2156-0023-00
3231-0123-00
3221-0063-00
3231-0122-00
2155-0009-00
2151-0015-00
3231-0120-00
3231-0121-00
3713-0022-00
3131-0182-00
3712-0013-00
3980-0102-00
3341-0007-00
2153-0003-00
4319-0015-00
2152-0072-00
3131-0159-00
4311-0068-00
SP-KFA1007
See below
3531-0015-00
3541-0020-00
3541-0039-00
SP-KFA1027
4343-0016-00
3431-0010-00
3311-0002-00
SP-KFA1008
4349-0017-00
4342-0009-00
4329-0013-00
3341-0016-00
See below
3970-0034-00
Capacitor
Motor Supportor
Lock Nut.
Pump Body
Bolt-PH
Insert
Rotor Kit
Blade
End Pump Cover
Nipple(Air)
Flange Bolt
Lint Filter
Output Filter
Filter Kit
End Filter Cover
Ball
Spring
Plug/Pump Adj.Kit
Flange Screw
Fan Assembly
Set Screw
Pressure Gauge
Fan Guard
Ignitor
Screw-PH2
Shell Upper Assembly
Shell Cover
Main P.C.B Assembly
Fuse
Thermostat Control Knob
Side Cover(R)
BRACKET SIDE COVER
RATING PLATE
Power Switch
Side Cover(L) 3820-0142-00
3121-0358-00
4331-0022-00
3541-0022-00
4321-0038-00
See SP-KFA1000
SP-KFA1000
See SP-KFA1000
3531-0008-00
3541-0020-00
4329-0014-00
See SP-KFA1005
See SP-KFA1005
SP-KFA1005
3221-0029-00
See SP-KFA1006
See SP-KFA1006
SP-KFA1006
4319-0015-00
2154-0009-00
4323-0004-00
3740-0049-01
3221-0050-00
39E0-0025-00
4311-0024-00
2151-0018-00
3211-0019-00
215A-0026-00
SP-KFA1018
3231-0111-01
3211-0021-00
3131-0348-00
3221-0058-00
39A0-0044-00
3211-0023-00
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21-1
21-2
21-3
21-4
21-5
21-6
21-7
21-8
21-9
21-10
21-11
22
23
23-1 23-2
23-3
23-4
23-5
23-6
23-7
23-8
23-9
23-10
23-11
23-12
23-13
23-14
23-15
23-16
23-17
23-18
23-19
23-20
24
25
26
27
28
29
30
31
32
32-1
32-2
33
34
35
36
37
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
13. EXPLODED PARTS DRAWING
