4
1 Door seal - Door seal maintains the microwave
energy within the oven cavity and prevents
microwave leakage.
2 Cover Heater
3 Heating Element
4 Oven cavity
5 Safety interlock system
6 Metal Rack
7 Coupler - This fits over the shaft in the center of
the ovens cavity floor. This is to remain in the
oven for all cooking.
8 Roller guide - This must always be used for
cooking together with the glass cooking tray.
9 Glass cooking tray - Made of special heat
resistant glass. Food in a proper receptacle is
placed on this tray for cooking.
0 Door viewing screen - Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwave.
q Door hook - When the door is closed, it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron will
immediately stop operating.
FEATURES DIAGRAM
1 2 3 4 5
q 0 7
9
8
6
